8BK1 | pdb_00008bk1

Mutant Imine Reductase IR007-143 from Amycolatopsis azurea, E120A, M197W, M206S, A213P, D238G, I240L

PDB DOI: https://doi.org/10.2210/pdb8BK1/pdb

Classification: OXIDOREDUCTASE
Organism(s): Amycolatopsis azurea
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2022-11-08 Released: 2023-09-20
Deposition Author(s): Gilio, A.K., Grogan, G.J.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free:
0.211 (Depositor), 0.221 (DCC)
R-Value Work:
0.188 (Depositor), 0.202 (DCC)
R-Value Observed:
0.189 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Engineering of a Reductive Aminase to Enable the Synthesis of a Key Intermediate to a CDK 2/4/6 Inhibitor

Steflik, J., Gilio, A., Burns, M., Grogan, G., Kumar, R., Lewis, R., Martinez, C.

(2023) ACS Catal 13: 10065-10075

DOI: https://doi.org/10.1021/acscatal.3c01534

Macromolecule Content

Total Structure Weight: 127.39 kDa
Atom Count: 9,070
Modeled Residue Count: 1,150
Deposited Residue Count: 1,152
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mutant Imine Reductase IR007-143 from Amycolatopsis azurea, E120A, M197W, M206S, A213P, D238G, I240L	A, B, C, D	288	Amycolatopsis azurea	Mutation(s): 6
UniProt
Find proteins for M2QI47 (Amycolatopsis azurea DSM 43854) Explore M2QI47 Go to UniProtKB: M2QI47
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	M2QI47
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAP (Subject of Investigation/LOI) Query on NAP Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain I [auth B] SDF format, chain L [auth C] SDF format, chain O [auth D] MOL2 format, chain E [auth A] MOL2 format, chain I [auth B] MOL2 format, chain L [auth C] MOL2 format, chain O [auth D] mmCIF format, chain E [auth A] mmCIF format, chain I [auth B] mmCIF format, chain L [auth C] mmCIF format, chain O [auth D]	E [auth A], I [auth B], L [auth C], O [auth D]	NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE C₂₁ H₂₈ N₇ O₁₇ P₃ XJLXINKUBYWONI-NNYOXOHSSA-N		Interactions Focus chain E [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain O [auth D] Interactions & Density Focus chain E [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain O [auth D]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain M [auth C] SDF format, chain N [auth C] SDF format, chain P [auth D] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain M [auth C] MOL2 format, chain N [auth C] MOL2 format, chain P [auth D] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain M [auth C] mmCIF format, chain N [auth C] mmCIF format, chain P [auth D]	F [auth A] G [auth A] H [auth A] J [auth B] K [auth B] F [auth A], G [auth A], H [auth A], J [auth B], K [auth B], M [auth C], N [auth C], P [auth D]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain M [auth C] Focus chain N [auth C] Focus chain P [auth D] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain M [auth C] Focus chain N [auth C] Focus chain P [auth D]
