8B16 | pdb_00008b16

A hexameric barrel state of a de novo coiled-coil assembly: CC-Pent2-I17Q

PDB DOI: https://doi.org/10.2210/pdb8B16/pdb

Classification: DE NOVO PROTEIN
Organism(s): synthetic construct
Mutation(s): No

Deposited: 2022-09-09 Released: 2023-09-20
Deposition Author(s): Martin, F.J.O., Dawson, W.M., Woolfson, D.N.
Funding Organization(s): European Research Council (ERC), Biotechnology and Biological Sciences Research Council (BBSRC), Engineering and Physical Sciences Research Council

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.55 Å
R-Value Free:
0.259 (Depositor), 0.263 (DCC)
R-Value Work:
0.219 (Depositor), 0.228 (DCC)
R-Value Observed:
0.221 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 8B16

This is version 1.1 of the entry. See complete history.

Literature

Exchange, promiscuity, and orthogonality in a set of de novo coiled-coil assemblies

Martin, F.J.O., Orr-Ewing, A.J., Dawson, W.M., Woolfson, D.N.

To be published.

Macromolecule Content

Total Structure Weight: 40.5 kDa
Atom Count: 2,894
Modeled Residue Count: 366
Deposited Residue Count: 384
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CC-Pent2-I17Q	A [auth E] B [auth A] C [auth B] D [auth L] E [auth F] A [auth E], B [auth A], C [auth B], D [auth L], E [auth F], F [auth D], G [auth K], H, I [auth G], J [auth I], K [auth C], L [auth J]	32	synthetic construct	Mutation(s): 0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain M [auth J] MOL2 format, chain M [auth J] mmCIF format, chain M [auth J]	M [auth J]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain M [auth J] Interactions & Density Focus chain M [auth J]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.55 Å
R-Value Free: 0.259 (Depositor), 0.263 (DCC)
R-Value Work: 0.219 (Depositor), 0.228 (DCC)
R-Value Observed: 0.221 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 31.885	α = 74.45
b = 43.292	β = 88.71
c = 57.216	γ = 86.99

Software Package:

Software Name	Purpose
Aimless	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
xia2	data reduction
Arcimboldo	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-09-20

Deposition Author(s):

Funding Organization	Location	Grant Number
European Research Council (ERC)	European Union	340764
Biotechnology and Biological Sciences Research Council (BBSRC)	United Kingdom	BB/L01386X/1
Engineering and Physical Sciences Research Council	United Kingdom	EP/G036764

Revision History (Full details and data files)

Version 1.0: 2023-09-20
Type: Initial release
Version 1.1: 2024-10-23
Changes: Structure summary
