8AZO

Structure of SARS-CoV-2 NSP3 macrodomain in complex with beta-ethyl-ADP

PDB DOI: https://doi.org/10.2210/pdb8AZO/pdb

Classification: VIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2022-09-06 Released: 2024-03-20
Deposition Author(s): Sander, S., Tidow, H., Fliegert, R., Sandmann, M.
Funding Organization(s): German Research Foundation (DFG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.232 (Depositor), 0.230 (DCC)
R-Value Work:
0.201 (Depositor), 0.200 (DCC)
R-Value Observed:
0.203 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Structure of SARS-CoV-2 NSP3 macrodomain in complex with beta-ethyl-ADP

Sander, S., Tidow, H., Fliegert, R., Sandmann, M.

To be published.

Macromolecule Content

Total Structure Weight: 39.47 kDa
Atom Count: 3,001
Modelled Residue Count: 343
Deposited Residue Count: 358
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Papain-like protease nsp3	A, B	179	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0 EC: 3.4.19.12 (PDB Primary Data), 3.4.22 (PDB Primary Data)
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1 Go to UniProtKB: P0DTD1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0DTD1
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
OIG (Subject of Investigation/LOI) Query on OIG Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth B]	C [auth A], D [auth B]	beta-ethyl-adenosine diphosphate C₁₂ H₁₉ N₅ O₁₀ P₂ OBBAXRNSCNGYQO-WOUKDFQISA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.232 (Depositor), 0.230 (DCC)
R-Value Work: 0.201 (Depositor), 0.200 (DCC)
R-Value Observed: 0.203 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.644	α = 90
b = 75.593	β = 90
c = 82.925	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing
Coot	model building

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2024-03-20

Deposition Author(s):

Funding Organization	Location	Grant Number
German Research Foundation (DFG)	Germany	SFB 1328

Revision History (Full details and data files)

Version 1.0: 2024-03-20
Type: Initial release
