8A5X

Crystal structure of phosphatidyl inositol 4-kinase II beta in complex with MM1373


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.210
  • R-Value Observed: 0.211

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Structure-based design and modular synthesis of novel PI4K class II inhibitors bearing a 4-aminoquinazoline scaffold.

Misehe, M.Klima, M.Matousova, M.Chalupska, D.Dejmek, M.Sala, M.Mertlikova-Kaiserova, H.Boura, E.Nencka, R.

(2022) Bioorg Med Chem Lett 76: 129010-129010

  • DOI: https://doi.org/10.1016/j.bmcl.2022.129010
  • Primary Citation of Related Structures:
    8A5X

  • PubMed Abstract:

    Novel 4-aminoquinazoline-6-carboxamide derivatives bearing differently substituted aryl or heteroaryl groups at position 7 in the core were rationally designed, synthesized and evaluated for biological activity in vitro as phosphatidylinositol 4-kinase IIα (PI4K2A) inhibitors. The straightforward approach described here enabled the sequential, modular synthesis and broad functionalization of the scaffold in a mere six steps. The SAR investigation reported here is based on detailed structural analysis of the conserved binding mode of ATP and other adenine derivatives to the catalytic site of type II PI4Ks, combined with extensive docking studies. Several compounds exhibited significant activity against PI4K2A. Moreover, we solved a crystal structure of PI4K2B in complex with one of our lead ligand candidates, which validated the ligand binding site and pose predicted by our docking-based ligand model. These discoveries suggest that our structure-based approach may be further developed and employed to synthesize new inhibitors with optimized potency and selectivity for this class of PI4Ks.


  • Organizational Affiliation

    Institute of Organic Chemistry and Biochemistry of the Czech Academy of Sciences, Flemingovo nam. 2, 166 10 Prague 6, Czech Republic; Department of Organic Chemistry, Faculty of Science, Charles University in Prague, Hlavova 2030/8, 128 43 Prague 2, Czech Republic.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Phosphatidylinositol 4-kinase type 2-beta,Endolysin514Homo sapiensMutation(s): 4
Gene Names: PI4K2B
EC: 2.7.1.67 (PDB Primary Data), 3.2.1.17 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q8TCG2 (Homo sapiens)
Explore Q8TCG2
Go to UniProtKB:  Q8TCG2
PHAROS:  Q8TCG2
GTEx:  ENSG00000038210
Find proteins for P00720 (Enterobacteria phage T4)
Explore P00720
Go to UniProtKB:  P00720
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsP00720Q8TCG2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
L6A (Subject of Investigation/LOI)
Query on L6A

Download Ideal Coordinates CCD File
B [auth A]4-azanyl-7-[3-(hydroxymethyl)phenyl]quinazoline-6-carboxamide
C16 H14 N4 O2
UNWGLQGHMTWDJL-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.210
  • R-Value Observed: 0.211
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.383α = 90
b = 87.007β = 107.78
c = 71.376γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XDSdata scaling
PHASERphasing
Cootmodel building
PHENIXrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2022-10-05
    Type: Initial release
  • Version 1.1: 2022-10-12
    Changes: Database references
  • Version 1.2: 2022-10-19
    Changes: Database references
  • Version 1.3: 2024-01-31
    Changes: Data collection, Refinement description
