8A33 | pdb_00008a33

Crystal structure of PpSB1-LOV-K117E mutant (light state)

PDB DOI: https://doi.org/10.2210/pdb8A33/pdb

Classification: SIGNALING PROTEIN
Organism(s): Pseudomonas putida KT2440
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): Yes

Deposited: 2022-06-07 Released: 2023-07-05
Deposition Author(s): Batra-Safferling, R., Granzin, J., Krauss, U.
Funding Organization(s): German Federal Ministry for Education and Research

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.95 Å
R-Value Free:
0.288 (Depositor), 0.294 (DCC)
R-Value Work:
0.232 (Depositor), 0.232 (DCC)
R-Value Observed:
0.238 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8A33

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of PpSB1-LOV-K117E mutant (light state)

Batra-Safferling, R., Granzin, J., Krauss, U.

To be published.

Macromolecule Content

Total Structure Weight: 19.08 kDa
Atom Count: 1,112
Modeled Residue Count: 133
Deposited Residue Count: 162
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sensory box protein	A	162	Pseudomonas putida KT2440	Mutation(s): 1 Gene Names: PP_4629
UniProt
Find proteins for Q88E39 (Pseudomonas putida (strain ATCC 47054 / DSM 6125 / CFBP 8728 / NCIMB 11950 / KT2440)) Explore Q88E39 Go to UniProtKB: Q88E39
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q88E39
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
JGC (Subject of Investigation/LOI) Query on JGC Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	Flavin mononucleotide (semi-quinone intermediate) C₁₇ H₂₃ N₄ O₉ P JNFNEOXSUODPSY-DGAVXFQQSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.95 Å
R-Value Free: 0.288 (Depositor), 0.294 (DCC)
R-Value Work: 0.232 (Depositor), 0.232 (DCC)
R-Value Observed: 0.238 (Depositor)

Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 54.329	α = 90
b = 54.329	β = 90
c = 220.555	γ = 120

Software Package:

Software Name	Purpose
MxCuBE	data collection
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-07-05

Deposition Author(s):

Batra-Safferling, R.

Funding Organization	Location	Grant Number
German Federal Ministry for Education and Research	Germany	FKZ 031A16

Revision History (Full details and data files)

Version 1.0: 2023-07-05
Type: Initial release
Version 1.1: 2024-02-07
Changes: Data collection, Refinement description
Version 1.2: 2024-10-16
Changes: Structure summary
