7ZJR | pdb_00007zjr

X-ray structure of the periplasmic region of PilJ from P. aeruginosa

PDB DOI: https://doi.org/10.2210/pdb7ZJR/pdb

Classification: SIGNALING PROTEIN
Organism(s): Pseudomonas aeruginosa PAO1
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2022-04-11 Released: 2022-04-27
Deposition Author(s): Pierrat, X., Pojer, F., Persat, A.
Funding Organization(s): Swiss National Science Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free:
0.245 (Depositor), 0.248 (DCC)
R-Value Work:
0.215 (Depositor), 0.221 (DCC)
R-Value Observed:
0.217 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7ZJR

This is version 1.1 of the entry. See complete history.

Literature

X-ray structure of the periplasmic region of PilJ from P. aeruginosa

Pierrat, X., Pojer, F., Persat, A.

To be published.

Macromolecule Content

Total Structure Weight: 31.76 kDa
Atom Count: 2,064
Modeled Residue Count: 268
Deposited Residue Count: 293
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein PilJ	A	293	Pseudomonas aeruginosa PAO1	Mutation(s): 0 Gene Names: pilJ, PA0411
UniProt
Find proteins for P42257 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore P42257 Go to UniProtKB: P42257
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P42257
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free: 0.245 (Depositor), 0.248 (DCC)
R-Value Work: 0.215 (Depositor), 0.221 (DCC)
R-Value Observed: 0.217 (Depositor)

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 80.059	α = 90
b = 80.059	β = 90
c = 202.994	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XDS	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-04-27

Deposition Author(s):

Funding Organization	Location	Grant Number
Swiss National Science Foundation	Switzerland	310030_189084

Revision History (Full details and data files)

Version 1.0: 2022-04-27
Type: Initial release
Version 1.1: 2024-01-31
Changes: Data collection, Refinement description
