7YTJ

Cryo-EM structure of VTC complex


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

The cytoplasmic synthesis and coupled membrane translocation of eukaryotic polyphosphate by signal-activated VTC complex.

Guan, Z.Chen, J.Liu, R.Chen, Y.Xing, Q.Du, Z.Cheng, M.Hu, J.Zhang, W.Mei, W.Wan, B.Wang, Q.Zhang, J.Cheng, P.Cai, H.Cao, J.Zhang, D.Yan, J.Yin, P.Hothorn, M.Liu, Z.

(2023) Nat Commun 14: 718-718

  • DOI: https://doi.org/10.1038/s41467-023-36466-4
  • Primary Citation of Related Structures:
    7YTJ

  • PubMed Abstract:

    Inorganic polyphosphate (polyP) is an ancient energy metabolite and phosphate store that occurs ubiquitously in all organisms. The vacuolar transporter chaperone (VTC) complex integrates cytosolic polyP synthesis from ATP and polyP membrane translocation into the vacuolar lumen. In yeast and in other eukaryotes, polyP synthesis is regulated by inositol pyrophosphate (PP-InsP) nutrient messengers, directly sensed by the VTC complex. Here, we report the cryo-electron microscopy structure of signal-activated VTC complex at 3.0 Å resolution. Baker's yeast VTC subunits Vtc1, Vtc3, and Vtc4 assemble into a 3:1:1 complex. Fifteen trans-membrane helices form a novel membrane channel enabling the transport of newly synthesized polyP into the vacuolar lumen. PP-InsP binding orients the catalytic polymerase domain at the entrance of the trans-membrane channel, both activating the enzyme and coupling polyP synthesis and membrane translocation. Together with biochemical and cellular studies, our work provides mechanistic insights into the biogenesis of an ancient energy metabolite.


  • Organizational Affiliation

    National Key Laboratory of Crop Genetic Improvement, Hubei Hongshan Laboratory, Huazhong Agricultural University, Wuhan, 430070, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Vacuolar transporter chaperone 4A [auth D]754Saccharomyces cerevisiaeMutation(s): 0
Gene Names: VTC4PHM3YJL012CJ1345
EC: 2.7.4.1
Membrane Entity: Yes
UniProt
Find proteins for P47075 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P47075
Go to UniProtKB:  P47075
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP47075
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Vacuolar transporter chaperone 1B [auth A],
C [auth B],
D [auth C]
143Saccharomyces cerevisiaeMutation(s): 0
Gene Names: VTC1NRF1PHM4YER072W
Membrane Entity: Yes
UniProt
Find proteins for P40046 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P40046
Go to UniProtKB:  P40046
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP40046
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Vacuolar transporter chaperone 3864Saccharomyces cerevisiaeMutation(s): 0
Gene Names: VTC3PHM2YPL019C
Membrane Entity: Yes
UniProt
Find proteins for Q02725 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q02725
Go to UniProtKB:  Q02725
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ02725
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PC1 (Subject of Investigation/LOI)
Query on PC1

Download Ideal Coordinates CCD File
H [auth D],
L [auth E]
1,2-DIACYL-SN-GLYCERO-3-PHOSPHOCHOLINE
C44 H88 N O8 P
NRJAVPSFFCBXDT-HUESYALOSA-N
IHP (Subject of Investigation/LOI)
Query on IHP

Download Ideal Coordinates CCD File
F [auth D],
G [auth D],
I [auth D]
INOSITOL HEXAKISPHOSPHATE
C6 H18 O24 P6
IMQLKJBTEOYOSI-GPIVLXJGSA-N
PO4 (Subject of Investigation/LOI)
Query on PO4

Download Ideal Coordinates CCD File
J [auth D],
K [auth D]
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China--

Revision History  (Full details and data files)

  • Version 1.0: 2023-02-22
    Type: Initial release
  • Version 1.1: 2024-07-03
    Changes: Data collection
