7YNF | pdb_00007ynf

CCA-bound alpha-synuclein fibrils

PDB DOI: https://doi.org/10.2210/pdb7YNF/pdb
EM Map EMD-33960: EMDB EMDataResource

Classification: PROTEIN FIBRIL
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2022-07-30 Released: 2023-12-06
Deposition Author(s): Tao, Y.Q., Zhao, Q.Y., Liu, C., Li, D.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.50 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

Validation slider image for 7YNF

This is version 1.0 of the entry. See complete history.

Literature

CCA-bound alpha-synuclein fibrils

Tao, Y.Q., Zhao, Q.Y., Liu, C., Li, D.

To be published.

Macromolecule Content

Total Structure Weight: 92.12 kDa
Atom Count: 2,988
Modeled Residue Count: 378
Deposited Residue Count: 840
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Alpha-synuclein	A, B, C, D, E A, B, C, D, E, F	140	Homo sapiens	Mutation(s): 0 Gene Names: SNCA, NACP, PARK1
UniProt & NIH Common Fund Data Resources
Find proteins for P37840 (Homo sapiens) Explore P37840 Go to UniProtKB: P37840
PHAROS: P37840 GTEx: ENSG00000145335
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P37840
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
V79 (Subject of Investigation/LOI) Query on V79 Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth C] SDF format, chain L [auth C] SDF format, chain M [auth C] SDF format, chain N [auth D] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth C] MOL2 format, chain L [auth C] MOL2 format, chain M [auth C] MOL2 format, chain N [auth D] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth C] mmCIF format, chain L [auth C] mmCIF format, chain M [auth C] mmCIF format, chain N [auth D]	G [auth A] H [auth A] I [auth A] J [auth A] K [auth C] G [auth A], H [auth A], I [auth A], J [auth A], K [auth C], L [auth C], M [auth C], N [auth D]	copper;trisodium;18-(2-carboxylatoethyl)-20-(carboxylatomethyl)-12-ethenyl-7-ethyl-3,8,13,17-tetramethyl-17,18-dihydroporphyrin-21,23-diide-2-carboxylate C₃₄ H₃₄ Cu N₄ O₆ YJPOIBSDHKWDGX-CQVJSGDESA-L		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth C] Focus chain L [auth C] Focus chain M [auth C] Focus chain N [auth D] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth C] Focus chain L [auth C] Focus chain M [auth C] Focus chain N [auth D]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.50 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-12-06

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2023-12-06
Type: Initial release
