7XJ8 | pdb_00007xj8

SARS-CoV-2 BA.1 Spike trimer in complex with 55A8 Fab and 58G6 Fab in the class 2 conformation

PDB DOI: https://doi.org/10.2210/pdb7XJ8/pdb
EM Map EMD-33221: EMDB EMDataResource

Classification: VIRAL PROTEIN/IMMUNE SYSTEM
Organism(s): Severe acute respiratory syndrome coronavirus 2, Homo sapiens
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2022-04-15 Released: 2023-04-19
Deposition Author(s): Guo, H., Gao, Y., Lu, Y., Yang, H., Ji, X.
Funding Organization(s): Other government

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.30 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

SARS-CoV-2 BA.1 Spike trimer in complex with 55A8 Fab and 58G6 Fab in the class 2 conformation

Guo, H., Gao, Y., Lu, Y., Yang, H., Ji, X.

To be published.

Macromolecule Content

Total Structure Weight: 512.7 kDa
Atom Count: 28,706
Modeled Residue Count: 3,597
Deposited Residue Count: 4,545
Unique protein chains: 5

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	A, B, C	1,285	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 39 Gene Names: S, 2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2 Go to UniProtKB: P0DTC2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0DTC2
Glycosylation
Glycosylation Sites: 10	Glycosylation Focus chain A Focus chain B Focus chain C	Go to GlyGen: P0DTC2-1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
55A8 light chain	D [auth F], F [auth H]	108	Homo sapiens	Mutation(s): 0

Find similar proteins by:

| 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
55A8 heavy chain	E [auth G], G [auth I]	121	Homo sapiens	Mutation(s): 0

Find similar proteins by:

| 3D Structure

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
58G6 light chain	H [auth J]	109	Homo sapiens	Mutation(s): 0

Find similar proteins by:

| 3D Structure

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
58G6 heavy chain	I [auth K]	123	Homo sapiens	Mutation(s): 0

Oligosaccharides

Help

Entity ID: 6
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	J [auth O], K [auth D], L [auth E], M [auth L], N [auth M], J [auth O], K [auth D], L [auth E], M [auth L], N [auth M], O [auth N], P, Q, R, S, T, U, V, W, X	2		N-Glycosylation	Interactions Focus chain J [auth O] Focus chain K [auth D] Focus chain L [auth E] Focus chain M [auth L] Focus chain N [auth M] Focus chain O [auth N] Focus chain P Focus chain Q Focus chain R Focus chain S Focus chain T Focus chain U Focus chain V Focus chain W Focus chain X Interactions & Density Focus chain J [auth O] Focus chain K [auth D] Focus chain L [auth E] Focus chain M [auth L] Focus chain N [auth M] Focus chain O [auth N] Focus chain P Focus chain Q Focus chain R Focus chain S Focus chain T Focus chain U Focus chain V Focus chain W Focus chain X
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG (Subject of Investigation/LOI) Query on NAG Download:Ideal Coordinates CCD File SDF format, chain Z [auth A] SDF format, chain Y [auth A] SDF format, chain MA [auth C] SDF format, chain LA [auth C] SDF format, chain KA [auth C] SDF format, chain JA [auth C] SDF format, chain IA [auth C] SDF format, chain HA [auth B] SDF format, chain GA [auth B] SDF format, chain FA [auth B] SDF format, chain EA [auth B] SDF format, chain DA [auth B] SDF format, chain CA [auth A] SDF format, chain BA [auth A] SDF format, chain AA [auth A] MOL2 format, chain Z [auth A] MOL2 format, chain Y [auth A] MOL2 format, chain MA [auth C] MOL2 format, chain LA [auth C] MOL2 format, chain KA [auth C] MOL2 format, chain JA [auth C] MOL2 format, chain IA [auth C] MOL2 format, chain HA [auth B] MOL2 format, chain GA [auth B] MOL2 format, chain FA [auth B] MOL2 format, chain EA [auth B] MOL2 format, chain DA [auth B] MOL2 format, chain CA [auth A] MOL2 format, chain BA [auth A] MOL2 format, chain AA [auth A] mmCIF format, chain Z [auth A] mmCIF format, chain Y [auth A] mmCIF format, chain MA [auth C] mmCIF format, chain LA [auth C] mmCIF format, chain KA [auth C] mmCIF format, chain JA [auth C] mmCIF format, chain IA [auth C] mmCIF format, chain HA [auth B] mmCIF format, chain GA [auth B] mmCIF format, chain FA [auth B] mmCIF format, chain EA [auth B] mmCIF format, chain DA [auth B] mmCIF format, chain CA [auth A] mmCIF format, chain BA [auth A] mmCIF format, chain AA [auth A]	AA [auth A] BA [auth A] CA [auth A] DA [auth B] EA [auth B] AA [auth A], BA [auth A], CA [auth A], DA [auth B], EA [auth B], FA [auth B], GA [auth B], HA [auth B], IA [auth C], JA [auth C], KA [auth C], LA [auth C], MA [auth C], Y [auth A], Z [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain AA [auth A] Focus chain BA [auth A] Focus chain CA [auth A] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth C] Focus chain JA [auth C] Focus chain KA [auth C] Focus chain LA [auth C] Focus chain MA [auth C] Focus chain Y [auth A] Focus chain Z [auth A] Interactions & Density Focus chain AA [auth A] Focus chain BA [auth A] Focus chain CA [auth A] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth C] Focus chain JA [auth C] Focus chain KA [auth C] Focus chain LA [auth C] Focus chain MA [auth C] Focus chain Y [auth A] Focus chain Z [auth A]
