7XA1 | pdb_00007xa1

Thermotoga maritima ferritin variant-Tm-E(S111Y)

PDB DOI: https://doi.org/10.2210/pdb7XA1/pdb

Classification: METAL BINDING PROTEIN
Organism(s): Thermotoga maritima
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2022-03-16 Released: 2023-03-22
Deposition Author(s): Yu, L., Guanghua, Z.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free:
0.279 (Depositor), 0.281 (DCC)
R-Value Work:
0.226 (Depositor), 0.227 (DCC)
R-Value Observed:
0.231 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7XA1

This is version 1.1 of the entry. See complete history.

Literature

Thermotoga maritima ferritin variant-Tm-E(S111Y)

Yu, L., Guanghua, Z.

To be published.

Macromolecule Content

Total Structure Weight: 17.57 kDa
Atom Count: 1,272
Modeled Residue Count: 143
Deposited Residue Count: 148
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ferritin	A	148	Thermotoga maritima	Mutation(s): 1 Gene Names: TM_1128 EC: 1.16.3.2
UniProt
Find proteins for Q9X0L2 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9X0L2 Go to UniProtKB: Q9X0L2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9X0L2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FE Query on FE Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	FE (III) ION Fe VTLYFUHAOXGGBS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free: 0.279 (Depositor), 0.281 (DCC)
R-Value Work: 0.226 (Depositor), 0.227 (DCC)
R-Value Observed: 0.231 (Depositor)

Space Group: P 3₂ 1 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.609	α = 90
b = 56.609	β = 90
c = 128.087	γ = 120

Software Package:

Software Name	Purpose
SCALEPACK	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-3000	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-03-22

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2023-03-22
Type: Initial release
Version 1.1: 2023-11-29
Changes: Data collection, Refinement description
