7X45 | pdb_00007x45

Grass carp interferon gamma related


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.26 Å
  • R-Value Free:
    0.268 (Depositor), 0.267 (DCC)
  • R-Value Work:
    0.221 (Depositor), 0.221 (DCC)

wwPDB Validation 3D Report Full Report

Validation slider image for 7X45

This is version 1.3 of the entry. See complete history

Literature

Novel Dimeric Architecture of an IFN-gamma-Related Cytokine Provides Insights into Subfunctionalization of Type II IFNs in Teleost Fish.

Zhu, X.Wang, J.Jia, Z.Feng, J.Wang, B.Wang, Z.Liu, Q.Wu, K.Huang, W.Zhao, X.Dang, H.Zou, J.

(2022) J Immunol 209: 2203-2214

  • DOI: https://doi.org/10.4049/jimmunol.2200334
  • Primary Citation Related Structures:
    7X45

  • PubMed Abstract:

    Gene duplication leads to subfunctionalization of paralogs. In mammals, IFN-γ is the sole member of the type II IFN family and binds to a receptor complex consisting of IFN-γR1 and IFN-γR2. In teleost fish, IFN-γ and its receptors have been duplicated due to the teleost-specific whole-genome duplication event. In this study, the functions of an IFN-γ-related (IFN-γrel) cytokine were found to be partially retained relative to IFN-γ in grass carp (Ctenopharyngodon idella [CiIFN-γrel]). CiIFN-γrel upregulated the expression of proinflammatory genes but had lost the ability to activate genes involved in Th1 response. The results suggest that CiIFN-γrel could have been subfunctionalized from CiIFN-γ. Moreover, CiIFN-γrel induced STAT1 phosphorylation via interaction with duplicated homologs of IFN-γR1 (cytokine receptor family B [CRFB] 17 and CRFB13). Strikingly, CiIFN-γrel did not bind to the IFN-γR2 homolog (CRFB6). To gain insight into the subfunctionalization, the crystal structure of CiIFN-γrel was solved at 2.26 Å, revealing that it forms a homodimer that is connected by two pairs of disulfide bonds. Due to the spatial positions of helix A, loop AB, and helix B, CiIFN-γrel displays a unique topology that requires elements from two identical monomers to form a unit that is similar to IFN-γ. Further, mutagenesis analyses identified key residues interacting with CiIFN-γrel receptors and those required for the biological functions. Our study can help understand the subfunctionalization of duplicated IFN-γ paralogs in fish.


  • Organizational Affiliation
    • Key Laboratory of Exploration and Utilization of Aquatic Genetic Resources, Ministry of Education, Shanghai Ocean University, Shanghai, China.

Macromolecule Content

  • Total Structure Weight: 39.3 kDa
  • Atom Count: 2,042
  • Modeled Residue Count: 244
  • Deposited Residue Count: 334
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Interferon gamma
A, B
167Ctenopharyngodon idellaMutation(s): 0
UniProt
Find proteins for C0LEE1 (Ctenopharyngodon idella)
Explore C0LEE1
Go to UniProtKB:  C0LEE1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC0LEE1
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.26 Å
  • R-Value Free:  0.268 (Depositor), 0.267 (DCC)
  • R-Value Work:  0.221 (Depositor), 0.221 (DCC)
Space Group: P 31 1 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.58α = 90
b = 48.58β = 90
c = 208.66γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
HKL-3000data reduction
HKL-3000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China32030112

Revision History  (Full details and data files)

  • Version 1.0: 2022-09-14
    Type: Initial release
  • Version 1.1: 2022-11-23
    Changes: Database references
  • Version 1.2: 2023-04-19
    Changes: Database references
  • Version 1.3: 2024-10-09
    Changes: Data collection, Structure summary
