7V23 | pdb_00007v23

CryoEM structure of del68-76/del679-688 prefusion-stabilized spike in complex with the Fab of N12-9

PDB DOI: https://doi.org/10.2210/pdb7V23/pdb
EM Map EMD-31635: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2, Homo sapiens
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2021-08-07 Released: 2022-08-10
Deposition Author(s): Du, S., Xiao, J.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.96 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

CryoEM structure of del68-76/del679-688 prefusion-stabilized spike in complex with the Fab of N12-9

Du, S., Xiao, J.

To be published.

Macromolecule Content

Total Structure Weight: 506.63 kDa
Atom Count: 29,633
Modeled Residue Count: 3,774
Deposited Residue Count: 4,500
Unique protein chains: 3

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	A, B, C	1,269	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 6 Gene Names: S, 2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2 Go to UniProtKB: P0DTC2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0DTC2
Glycosylation
Glycosylation Sites: 11	Glycosylation Focus chain A Focus chain B Focus chain C	Go to GlyGen: P0DTC2-1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
the heavy chain of N12-9 Fab	D [auth O], F [auth Q], H [auth S]	125	Homo sapiens	Mutation(s): 0

Find similar proteins by:

| 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
the light chain of N12-9 Fab	E [auth P], G [auth R], I [auth T]	106	Homo sapiens	Mutation(s): 0

Oligosaccharides

Help

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	J [auth D], K [auth E], L [auth F], M [auth G], N [auth H], J [auth D], K [auth E], L [auth F], M [auth G], N [auth H], O [auth J], P [auth K], Q [auth L], R [auth M], S [auth N]	2		N-Glycosylation	Interactions Focus chain J [auth D] Focus chain K [auth E] Focus chain L [auth F] Focus chain M [auth G] Focus chain N [auth H] Focus chain O [auth J] Focus chain P [auth K] Focus chain Q [auth L] Focus chain R [auth M] Focus chain S [auth N] Interactions & Density Focus chain J [auth D] Focus chain K [auth E] Focus chain L [auth F] Focus chain M [auth G] Focus chain N [auth H] Focus chain O [auth J] Focus chain P [auth K] Focus chain Q [auth L] Focus chain R [auth M] Focus chain S [auth N]
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG (Subject of Investigation/LOI) Query on NAG Download:Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain BA [auth B] SDF format, chain CA [auth B] SDF format, chain DA [auth B] SDF format, chain EA [auth B] SDF format, chain FA [auth B] SDF format, chain GA [auth B] SDF format, chain HA [auth B] SDF format, chain IA [auth B] SDF format, chain JA [auth B] SDF format, chain KA [auth B] SDF format, chain LA [auth B] SDF format, chain MA [auth C] SDF format, chain NA [auth C] SDF format, chain OA [auth C] SDF format, chain PA [auth C] SDF format, chain QA [auth C] SDF format, chain RA [auth C] SDF format, chain SA [auth C] SDF format, chain T [auth A] SDF format, chain TA [auth C] SDF format, chain U [auth A] SDF format, chain UA [auth C] SDF format, chain V [auth A] SDF format, chain W [auth A] SDF format, chain X [auth A] SDF format, chain Y [auth A] SDF format, chain Z [auth A] MOL2 format, chain AA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain CA [auth B] MOL2 format, chain DA [auth B] MOL2 format, chain EA [auth B] MOL2 format, chain FA [auth B] MOL2 format, chain GA [auth B] MOL2 format, chain HA [auth B] MOL2 format, chain IA [auth B] MOL2 format, chain JA [auth B] MOL2 format, chain KA [auth B] MOL2 format, chain LA [auth B] MOL2 format, chain MA [auth C] MOL2 format, chain NA [auth C] MOL2 format, chain OA [auth C] MOL2 format, chain PA [auth C] MOL2 format, chain QA [auth C] MOL2 format, chain RA [auth C] MOL2 format, chain SA [auth C] MOL2 format, chain T [auth A] MOL2 format, chain TA [auth C] MOL2 format, chain U [auth A] MOL2 format, chain UA [auth C] MOL2 format, chain V [auth A] MOL2 format, chain W [auth A] MOL2 format, chain X [auth A] MOL2 format, chain Y [auth A] MOL2 format, chain Z [auth A] mmCIF format, chain AA [auth B] mmCIF format, chain BA [auth B] mmCIF format, chain CA [auth B] mmCIF format, chain DA [auth B] mmCIF format, chain EA [auth B] mmCIF format, chain FA [auth B] mmCIF format, chain GA [auth B] mmCIF format, chain HA [auth B] mmCIF format, chain IA [auth B] mmCIF format, chain JA [auth B] mmCIF format, chain KA [auth B] mmCIF format, chain LA [auth B] mmCIF format, chain MA [auth C] mmCIF format, chain NA [auth C] mmCIF format, chain OA [auth C] mmCIF format, chain PA [auth C] mmCIF format, chain QA [auth C] mmCIF format, chain RA [auth C] mmCIF format, chain SA [auth C] mmCIF format, chain T [auth A] mmCIF format, chain TA [auth C] mmCIF format, chain U [auth A] mmCIF format, chain UA [auth C] mmCIF format, chain V [auth A] mmCIF format, chain W [auth A] mmCIF format, chain X [auth A] mmCIF format, chain Y [auth A] mmCIF format, chain Z [auth A]	AA [auth B] BA [auth B] CA [auth B] DA [auth B] EA [auth B] AA [auth B], BA [auth B], CA [auth B], DA [auth B], EA [auth B], FA [auth B], GA [auth B], HA [auth B], IA [auth B], JA [auth B], KA [auth B], LA [auth B], MA [auth C], NA [auth C], OA [auth C], PA [auth C], QA [auth C], RA [auth C], SA [auth C], T [auth A], TA [auth C], U [auth A], UA [auth C], V [auth A], W [auth A], X [auth A], Y [auth A], Z [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain LA [auth B] Focus chain MA [auth C] Focus chain NA [auth C] Focus chain OA [auth C] Focus chain PA [auth C] Focus chain QA [auth C] Focus chain RA [auth C] Focus chain SA [auth C] Focus chain T [auth A] Focus chain TA [auth C] Focus chain U [auth A] Focus chain UA [auth C] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A] Interactions & Density Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain LA [auth B] Focus chain MA [auth C] Focus chain NA [auth C] Focus chain OA [auth C] Focus chain PA [auth C] Focus chain QA [auth C] Focus chain RA [auth C] Focus chain SA [auth C] Focus chain T [auth A] Focus chain TA [auth C] Focus chain U [auth A] Focus chain UA [auth C] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A]
