7TBO | pdb_00007tbo

LOV2-DARPIN fusion : D12

PDB DOI: https://doi.org/10.2210/pdb7TBO/pdb

Classification: DE NOVO PROTEIN
Organism(s): synthetic construct
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2021-12-22 Released: 2023-07-05
Deposition Author(s): Mittl, P.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.32 Å
R-Value Free:
0.284 (Depositor), 0.290 (DCC)
R-Value Work:
0.196 (Depositor), 0.203 (DCC)
R-Value Observed:
0.201 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7TBO

This is version 1.1 of the entry. See complete history.

Literature

LOV2-DARPIN fusion : D12

Mittl, P.R.

To be published.

Macromolecule Content

Total Structure Weight: 76.63 kDa
Atom Count: 5,634
Modeled Residue Count: 677
Deposited Residue Count: 688
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
D12 LOV2-DARPin fusion	A, B	344	synthetic construct	Mutation(s): 0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.32 Å
R-Value Free: 0.284 (Depositor), 0.290 (DCC)
R-Value Work: 0.196 (Depositor), 0.203 (DCC)
R-Value Observed: 0.201 (Depositor)

Diffraction Data:

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.356	α = 68.57
b = 71.645	β = 83.13
c = 78.844	γ = 90.05

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
autoPROC	data reduction
STARANISO	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-07-05

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2023-07-05
Type: Initial release
Version 1.1: 2023-10-25
Changes: Data collection, Refinement description
