7S7Y

Crystal structure of iCytSnFR Cytisine Sensor precursor binding protein

• PDB DOI: https://doi.org/10.2210/pdb7S7Y/pdb

• Classification: FLUORESCENT PROTEIN
• Organism(s): Thermoanaerobacter sp. X513
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2021-09-17 Released: 2021-10-13
• Deposition Author(s): Fan, C., Nichols, N.L., Luebbert, L., Looger, L.L., Lester, H.A., Rees, D.C.
• Funding Organization(s): Howard Hughes Medical Institute (HHMI), National Institutes of Health/National Institute on Drug Abuse (NIH/NIDA), Tobacco-Related Disease Research Program (TRDRP)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.30 Å
• R-Value Free: 0.202
• R-Value Work: 0.180
• R-Value Observed: 0.181

Literature

Structure, Function, and Application of Bacterial ABC Transporters

Fan, C.

(2020) Ph D Thesis,california Institute Of Technology

• DOI: https://doi.org/10.7907/5t65-0047

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 33.17 kDa
• Atom Count: 2,503
• Modelled Residue Count: 278
• Deposited Residue Count: 293
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
iNicSnFR 4.0 Fluorescent Nicotine Sensor precursor binding protein	A	293	Thermoanaerobacter sp. X513	Mutation(s): 0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
IMD	B [auth A]	IMIDAZOLE C3 H5 N2 RAXXELZNTBOGNW-UHFFFAOYSA-O

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.30 Å
• R-Value Free: 0.202
• R-Value Work: 0.180
• R-Value Observed: 0.181
• Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.688	α = 90
b = 61.1	β = 100.64
c = 58.546	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PHASER	phasing
Aimless	data scaling
XDS	data reduction
Blu-Ice	data collection

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2021-10-13
Deposition Author(s): Fan, C., Nichols, N.L., Luebbert, L., Looger, L.L., Lester, H.A., Rees, D.C.

---

Funding Organization	Location	Grant Number
Howard Hughes Medical Institute (HHMI)	United States	--
National Institutes of Health/National Institute on Drug Abuse (NIH/NIDA)	United States	DA037161
National Institutes of Health/National Institute on Drug Abuse (NIH/NIDA)	United States	DA043829
National Institutes of Health/National Institute on Drug Abuse (NIH/NIDA)	United States	GM123582
Tobacco-Related Disease Research Program (TRDRP)	United States	23XT-0007
Tobacco-Related Disease Research Program (TRDRP)	United States	27IP-0057

Revision History

• Version 1.0: 2021-10-13
  Type: Initial release

• Version 1.1: 2021-11-03
  Changes: Structure summary
• Version 1.2: 2022-04-27
  Changes: Database references
• Version 1.3: 2023-10-18
  Changes: Data collection, Refinement description
