7S01 | pdb_00007s01

X-ray structure of the phage AR9 non-virion RNA polymerase holoenzyme in complex with a forked oligonucleotide containing the P077 promoter


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.40 Å
  • R-Value Free:
    0.293 (Depositor), 0.291 (DCC)
  • R-Value Work:
    0.239 (Depositor), 0.239 (DCC)
  • R-Value Observed:
    0.242 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7S01

This is version 2.1 of the entry. See complete history

Literature

Structural basis of template strand deoxyuridine promoter recognition by a viral RNA polymerase.

Fraser, A.Sokolova, M.L.Drobysheva, A.V.Gordeeva, J.V.Borukhov, S.Jumper, J.Severinov, K.V.Leiman, P.G.

(2022) Nat Commun 13: 3526-3526

  • DOI: https://doi.org/10.1038/s41467-022-31214-6
  • Primary Citation Related Structures:
    7S00, 7S01, 7UM0, 7UM1

  • PubMed Abstract:

    Recognition of promoters in bacterial RNA polymerases (RNAPs) is controlled by sigma subunits. The key sequence motif recognized by the sigma, the -10 promoter element, is located in the non-template strand of the double-stranded DNA molecule ~10 nucleotides upstream of the transcription start site. Here, we explain the mechanism by which the phage AR9 non-virion RNAP (nvRNAP), a bacterial RNAP homolog, recognizes the -10 element of its deoxyuridine-containing promoter in the template strand. The AR9 sigma-like subunit, the nvRNAP enzyme core, and the template strand together form two nucleotide base-accepting pockets whose shapes dictate the requirement for the conserved deoxyuridines. A single amino acid substitution in the AR9 sigma-like subunit allows one of these pockets to accept a thymine thus expanding the promoter consensus. Our work demonstrates the extent to which viruses can evolve host-derived multisubunit enzymes to make transcription of their own genes independent of the host.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Biology, Sealy Center for Structural Biology and Molecular Biophysics, University of Texas Medical Branch, Galveston, TX, 77555-0647, USA.

Macromolecule Content

  • Total Structure Weight: 340.71 kDa
  • Atom Count: 23,345
  • Modeled Residue Count: 2,731
  • Deposited Residue Count: 2,774
  • Unique protein chains: 5
  • Unique nucleic acid chains: 2

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit464Bacillus phage AR9Mutation(s): 0
Gene Names: AR9_g226
UniProt
Find proteins for A0A172JIC8 (Bacillus phage AR9)
Explore A0A172JIC8
Go to UniProtKB:  A0A172JIC8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A172JIC8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase beta' subunitB [auth d]426Bacillus phage AR9Mutation(s): 0
Gene Names: AR9_g270
EC: 2.7.7.6
UniProt
Find proteins for A0A172JIH0 (Bacillus phage AR9)
Explore A0A172JIH0
Go to UniProtKB:  A0A172JIH0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A172JIH0
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase beta subunitC [auth c]496Bacillus phage AR9Mutation(s): 0
Gene Names: AR9_g105
UniProt
Find proteins for A0A172JI16 (Bacillus phage AR9)
Explore A0A172JI16
Go to UniProtKB:  A0A172JI16
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A172JI16
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase631Bacillus phage AR9Mutation(s): 0
Gene Names: AR9_g154
EC: 2.7.7.6
UniProt
Find proteins for A0A172JI62 (Bacillus phage AR9)
Explore A0A172JI62
Go to UniProtKB:  A0A172JI62
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A172JI62
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymeraseE [auth C]665Bacillus phage AR9Mutation(s): 0
Gene Names: AR9_g089
EC: 2.7.7.6
UniProt
Find proteins for A0A172JHZ2 (Bacillus phage AR9)
Explore A0A172JHZ2
Go to UniProtKB:  A0A172JHZ2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A172JHZ2
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 6
MoleculeChains LengthOrganismImage
Non-template strand of the forked DNA oligonucleotide (downstream copy)F [auth N],
H [auth t]
14Bacillus phage AR9
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 7
MoleculeChains LengthOrganismImage
Template strand of the forked DNA oligonucleotide (downstream copy) containing the P077 AR9 promoter motifG [auth T],
I [auth n]
32Bacillus phage AR9
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN

Query on ZN



Download:Ideal Coordinates CCD File
J [auth D]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.40 Å
  • R-Value Free:  0.293 (Depositor), 0.291 (DCC)
  • R-Value Work:  0.239 (Depositor), 0.239 (DCC)
  • R-Value Observed: 0.242 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 176.925α = 90
b = 110.455β = 98.52
c = 222.379γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing
Cootmodel building

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not fundedFunded by UTMB

Revision History  (Full details and data files)

  • Version 1.0: 2022-07-06
    Type: Initial release
  • Version 1.1: 2024-04-03
    Changes: Data collection, Refinement description
  • Version 2.0: 2024-05-29
    Changes: Advisory, Atomic model, Author supporting evidence, Data collection, Derived calculations, Non-polymer description, Other, Refinement description, Structure summary
  • Version 2.1: 2025-02-12
    Changes: Refinement description, Structure summary
