7RUR | pdb_00007rur

Crystal structure of the hexadecameric form of Rv3208A

PDB DOI: https://doi.org/10.2210/pdb7RUR/pdb

Classification: UNKNOWN FUNCTION
Organism(s): Mycobacterium tuberculosis
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-08-18 Released: 2022-08-24
Deposition Author(s): Mandyoli, L., Sacchettini, J.C.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.239 (Depositor), 0.240 (DCC)
R-Value Work:
0.210 (Depositor), 0.210 (DCC)
R-Value Observed:
0.211 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of the hexadecameric form of Rv3208A

Mandyoli, L., Sacchettini, J.C.

To be published.

Macromolecule Content

Total Structure Weight: 37.65 kDa
Atom Count: 2,090
Modeled Residue Count: 257
Deposited Residue Count: 360
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Conserved protein of uncharacterized function, TB9.4	A, B, C, D	90	Mycobacterium tuberculosis	Mutation(s): 0 Gene Names: TB9, ERS007657_03239, ERS007663_03465, ERS007665_00399, ERS007679_02765, ERS007681_00484, ERS007688_02533, ERS007703_00624, ERS007720_01055, ERS007722_01831... TB9, ERS007657_03239, ERS007663_03465, ERS007665_00399, ERS007679_02765, ERS007681_00484, ERS007688_02533, ERS007703_00624, ERS007720_01055, ERS007722_01831, ERS007741_00499, ERS013471_01042, ERS023446_00265, ERS024276_00959, ERS027659_01325, ERS027661_04156, ERS094182_00478, F6W99_01850, SAMEA2683035_03896
UniProt
Find proteins for Q6MWZ8 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore Q6MWZ8 Go to UniProtKB: Q6MWZ8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q6MWZ8
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.239 (Depositor), 0.240 (DCC)
R-Value Work: 0.210 (Depositor), 0.210 (DCC)
R-Value Observed: 0.211 (Depositor)

Space Group: I 4

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 86.098	α = 90
b = 86.098	β = 90
c = 70.747	γ = 90

Software Package:

Software Name	Purpose
Coot	model building
PHENIX	refinement
DENZO	data reduction
SCALEPACK	data scaling
SHELX	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2022-08-24

Deposition Author(s):

Sacchettini, J.C.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History (Full details and data files)

Version 1.0: 2022-08-24
Type: Initial release
Version 1.1: 2024-05-22
Changes: Data collection
