7RGE | pdb_00007rge

Crystal structure of phosphoadenylyl-sulfate (PAPS) reductase from Candida auris, phosphate complex

PDB DOI: https://doi.org/10.2210/pdb7RGE/pdb

Classification: OXIDOREDUCTASE
Organism(s): Candidozyma auris
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2021-07-15 Released: 2021-07-28
Deposition Author(s): Stogios, P.J., Evdokimova, E., Di Leo, R., Savchenko, A., Joachimiak, A., Satchell, K.J.F., Center for Structural Genomics of Infectious Diseases (CSGID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.38 Å
R-Value Free:
0.221 (Depositor), 0.222 (DCC)
R-Value Work:
0.186 (Depositor), 0.185 (DCC)
R-Value Observed:
0.188 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7RGE

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of phosphoadenylyl-sulfate (PAPS) reductase from Candida auris, phosphate complex

Stogios, P.J.

To be published.

Macromolecule Content

Total Structure Weight: 27.88 kDa
Atom Count: 1,754
Modeled Residue Count: 203
Deposited Residue Count: 246
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
3'-phosphoadenylylsulfate reductase	A	246	Candidozyma auris	Mutation(s): 3 Gene Names: CAJCM15448_15210, CJI96_0004094 EC: 1.8.4.8
UniProt
Find proteins for A0A2H0ZDA4 (Candidozyma auris) Explore A0A2H0ZDA4 Go to UniProtKB: A0A2H0ZDA4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A2H0ZDA4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.38 Å
R-Value Free: 0.221 (Depositor), 0.222 (DCC)
R-Value Work: 0.186 (Depositor), 0.185 (DCC)
R-Value Observed: 0.188 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 109.508	α = 90
b = 132	β = 90
c = 44.617	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
PHASER	phasing
PHENIX	model building
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2021-07-28

Deposition Author(s):

Satchell, K.J.F.

Center for Structural Genomics of Infectious Diseases (CSGID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700060C

Revision History (Full details and data files)

Version 1.0: 2021-07-28
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Database references, Refinement description
