7R6H

RHCC in complex with o-carborane


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.222
  • R-Value Observed: 0.225

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Boron rich nanotube drug carrier system is suited for boron neutron capture therapy.

Heide, F.McDougall, M.Harder-Viddal, C.Roshko, R.Davidson, D.Wu, J.Aprosoff, C.Moya-Torres, A.Lin, F.Stetefeld, J.

(2021) Sci Rep 11: 15520-15520

  • DOI: https://doi.org/10.1038/s41598-021-95044-0
  • Primary Citation of Related Structures:
    7R6H

  • PubMed Abstract:

    Boron neutron capture therapy (BNCT) is a two-step therapeutic process that utilizes Boron-10 in combination with low energy neutrons to effectively eliminate targeted cells. This therapy is primarily used for difficult to treat head and neck carcinomas; recent advances have expanded this method to cover a broader range of carcinomas. However, it still remains an unconventional therapy where one of the barriers for widespread adoption is the adequate delivery of Boron-10 to target cells. In an effort to address this issue, we examined a unique nanoparticle drug delivery system based on a highly stable and modular proteinaceous nanotube. Initially, we confirmed and structurally analyzed ortho-carborane binding into the cavities of the nanotube. The high ratio of Boron to proteinaceous mass and excellent thermal stability suggest the nanotube system as a suitable candidate for drug delivery into cancer cells. The full physicochemical characterization of the nanotube then allowed for further mechanistic molecular dynamic studies of the ortho-carborane uptake and calculations of corresponding energy profiles. Visualization of the binding event highlighted the protein dynamics and the importance of the interhelical channel formation to allow movement of the boron cluster into the nanotube. Additionally, cell assays showed that the nanotube can penetrate outer membranes of cancer cells followed by localization around the cells' nuclei. This work uses an integrative approach combining experimental data from structural, molecular dynamics simulations and biological experiments to thoroughly present an alternative drug delivery device for BNCT which offers additional benefits over current delivery methods.


  • Organizational Affiliation

    Department of Chemistry, University of Manitoba, Winnipeg, MB, R3T 2N2, Canada. Heidef@myumanitoba.ca.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Tetrabrachion
A, B, C, D
52Staphylothermus marinusMutation(s): 0
UniProt
Find proteins for Q54436 (Staphylothermus marinus)
Explore Q54436
Go to UniProtKB:  Q54436
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ54436
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.222
  • R-Value Observed: 0.225
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 34.45α = 90
b = 55.92β = 90
c = 110.23γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Canadian Institutes of Health Research (CIHR)Canada201610PJT-152935
Natural Sciences and Engineering Research Council (NSERC, Canada)CanadaRGPIN-004954-2017

Revision History  (Full details and data files)

  • Version 1.0: 2021-07-07
    Type: Initial release
  • Version 1.1: 2022-01-19
    Changes: Database references
  • Version 1.2: 2023-10-18
    Changes: Data collection, Refinement description
