7QQ0 | pdb_00007qq0

X-ray structure of the adduct obtained upon reaction of [cis-Rh2(OCOCH3)2(OCOCF3)2] with RNase A (2)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.32 Å
  • R-Value Free:
    0.243 (Depositor), 0.256 (DCC)
  • R-Value Work:
    0.209 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7QQ0

This is version 1.2 of the entry. See complete history

Literature

Reactivity of a fluorine-containing dirhodium tetracarboxylate compound with proteins.

Loreto, D.Esposito, A.Demitri, N.Guaragna, A.Merlino, A.

(2022) Dalton Trans 51: 3695-3705

  • DOI: https://doi.org/10.1039/d2dt00082b
  • Primary Citation Related Structures:
    7QPW, 7QPY, 7QPZ, 7QQ0, 7QQ1

  • PubMed Abstract:

    Dirhodium complexes of general formula [Rh 2 (O 2 CR) 4 ]L 2 are a well-known class of bimetallic compounds that are used as efficient catalysts for a variety of reactions and have been shown to be potent antibacterial and anticancer agents. The catalytic and biological properties of these complexes largely depend on the nature of the bridging carboxylate ligands. Trifluoroacetate (tfa)-containing dirhodium compounds have been used to build artificial metalloenzymes upon reaction with peptides and have been shown to be more cytotoxic than dirhodium tetraacetate. However, there is no structural information on the interaction between these compounds and proteins. Here, cis -Rh 2 (μ-O 2 CCH 3 ) 2 (μ-O 2 CCF 3 ) 2 ([ cis -Rh 2 (OAc) 2 (tfa) 2 ]) has been synthesized and its reaction with bovine pancreatic ribonuclease (RNase A) and hen egg white lysozyme (HEWL) was analyzed using a combination of different techniques, including Fluorine-19 nuclear magnetic resonance spectroscopy and macromolecular X-ray crystallography, with the aim to unveil the differences in the reactivity of tfa-containing dihrodium complexes with proteins when compared to [Rh 2 (OAc) 4 ]. [ cis -Rh 2 (OAc) 2 (tfa) 2 ] and [Rh 2 (OAc) 4 ] bind the N atoms of His side chains of RNase A at the axial position; however the fluorine-containing compound rapidly loses its tfa ligands, while [Rh 2 (OAc) 4 ] can retain the acetate ligands upon protein binding. The reactivity of [ cis -Rh 2 (OAc) 2 (tfa) 2 ] with HEWL is slightly distinct when compared to that of [Rh 2 (OAc) 4 ] under the same experimental conditions; however, both [ cis -Rh 2 (OAc) 2 (tfa) 2 ] and [Rh 2 (OAc) 4 ] degrade when soaked within HEWL crystals. These results provide a structural-based guide for the design of new heterogenous chiral dirhodium/peptide and dirhodium/protein adducts with application in the fields of organic synthesis and asymmetric catalysis.


  • Organizational Affiliation
    • Department of Chemical Sciences, University of Naples Federico II, Complesso Universitario di Monte Sant'Angelo, via Cinthia 21, 80126 Naples, Italy. antonello.merlino@unina.it.

Macromolecule Content

  • Total Structure Weight: 28.36 kDa
  • Atom Count: 2,450
  • Modeled Residue Count: 248
  • Deposited Residue Count: 248
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ribonuclease pancreaticA [auth AAA],
B [auth BBB]
124Bos taurusMutation(s): 0
EC: 4.6.1.18
UniProt
Find proteins for P61823 (Bos taurus)
Explore P61823
Go to UniProtKB:  P61823
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP61823
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.32 Å
  • R-Value Free:  0.243 (Depositor), 0.256 (DCC)
  • R-Value Work:  0.209 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 100.21α = 90
b = 32.56β = 90.309
c = 72.61γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
AutoProcessdata reduction
AutoProcessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not fundedItaly--

Revision History  (Full details and data files)

  • Version 1.0: 2022-12-14
    Type: Initial release
  • Version 1.1: 2024-01-31
    Changes: Data collection, Refinement description
  • Version 1.2: 2024-11-13
    Changes: Structure summary
