7QOU

A mutant of the nitrile hydratase from Geobacillus pallidus having enhanced thermostability


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free: 0.182
  • R-Value Work: 0.153
  • R-Value Observed: 0.154

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Engineering enhanced thermostability into the Geobacillus pallidus nitrile hydratase.

Van Wyk, J.C.Sewell, B.T.Danson, M.J.Tsekoa, T.L.Sayed, M.F.Cowan, D.A.

(2022) Curr Res Struct Biol 4: 256-270

  • DOI: https://doi.org/10.1016/j.crstbi.2022.07.002
  • Primary Citation of Related Structures:
    7QOP, 7QOU, 7QOV, 7Z0V

  • PubMed Abstract:

    Nitrile hydratases (NHases) are important biocatalysts for the enzymatic conversion of nitriles to industrially-important amides such as acrylamide and nicotinamide. Although thermostability in this enzyme class is generally low, there is not sufficient understanding of its basis for rational enzyme design. The gene expressing the Co-type NHase from the moderate thermophile, Geobacillus pallidus RAPc8 (NRRL B-59396), was subjected to random mutagenesis. Four mutants were selected that were 3 to 15-fold more thermostable than the wild-type NHase, resulting in a 3.4-7.6 ​kJ/mol increase in the activation energy of thermal inactivation at 63 ​°C. High resolution X-ray crystal structures (1.15-1.80 ​Å) were obtained of the wild-type and four mutant enzymes. Mutant 9E, with a resolution of 1.15 ​Å, is the highest resolution crystal structure obtained for a nitrile hydratase to date. Structural comparisons between the wild-type and mutant enzymes illustrated the importance of salt bridges and hydrogen bonds in enhancing NHase thermostability. These additional interactions variously improved thermostability by increased intra- and inter-subunit interactions, preventing cooperative unfolding of α-helices and stabilising loop regions. Some hydrogen bonds were mediated via a water molecule, specifically highlighting the significance of structured water molecules in protein thermostability. Although knowledge of the mutant structures makes it possible to rationalize their behaviour, it would have been challenging to predict in advance that these mutants would be stabilising.


  • Organizational Affiliation

    Institute for Microbial Biotechnology and Metagenomics, University of the Western Cape, Bellville, 7535, South Africa.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Nitrile hydratase216Aeribacillus pallidusMutation(s): 1
EC: 4.2.1.84
UniProt
Find proteins for Q84FS5 (Bacillus sp. RAPc8)
Explore Q84FS5
Go to UniProtKB:  Q84FS5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ84FS5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Nitrile hydratase subunit beta229Aeribacillus pallidusMutation(s): 2
EC: 4.2.1.84
UniProt
Find proteins for Q84FS6 (Bacillus sp. RAPc8)
Explore Q84FS6
Go to UniProtKB:  Q84FS6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ84FS6
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free: 0.182
  • R-Value Work: 0.153
  • R-Value Observed: 0.154
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 106.084α = 90
b = 106.084β = 90
c = 82.975γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
d*TREKdata reduction
d*TREKdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Research Foundation in South AfricaSouth Africa--

Revision History  (Full details and data files)

  • Version 1.0: 2023-01-18
    Type: Initial release
  • Version 1.1: 2024-01-31
    Changes: Data collection, Database references, Refinement description
  • Version 1.2: 2024-10-23
    Changes: Structure summary
