7P97

Structure of 3-phospho-D-glycerate guanylyltransferase with product 3-GPPG bound


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.35 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.186

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Diversification by CofC and Control by CofD Govern Biosynthesis and Evolution of Coenzyme F 420 and Its Derivative 3PG-F 420.

Hasan, M.Schulze, S.Berndt, L.Palm, G.J.Braga, D.Richter, I.Last, D.Lammers, M.Lackner, G.

(2022) mBio 13: e0350121-e0350121

  • DOI: https://doi.org/10.1128/mbio.03501-21
  • Primary Citation of Related Structures:
    7P97

  • PubMed Abstract:

    Coenzyme F 420 is a microbial redox cofactor that mediates diverse physiological functions and is increasingly used for biocatalytic applications. Recently, diversified biosynthetic routes to F 420 and the discovery of a derivative, 3PG-F 420 , were reported. 3PG-F 420 is formed via activation of 3-phospho-d-glycerate (3-PG) by CofC, but the structural basis of substrate binding, its evolution, as well as the role of CofD in substrate selection remained elusive. Here, we present a crystal structure of the 3-PG-activating CofC from Mycetohabitans sp. B3 and define amino acids governing substrate specificity. Site-directed mutagenesis enabled bidirectional switching of specificity and thereby revealed the short evolutionary trajectory to 3PG-F 420 formation. Furthermore, CofC stabilized its product, thus confirming the structure of the unstable molecule and revealing its binding mode. The CofD enzyme was shown to significantly contribute to the selection of related intermediates to control the specificity of the combined biosynthetic CofC/D step. These results imply the need to change the design of combined CofC/D activity assays. Taken together, this work presents novel mechanistic and structural insights into 3PG-F 420 biosynthesis and evolution and opens perspectives for the discovery and enhanced biotechnological production of coenzyme F 420 derivatives in the future. IMPORTANCE The microbial cofactor F 420 is crucial for processes like methanogenesis, antibiotics biosynthesis, drug resistance, and biocatalysis. Recently, a novel derivative of F 420 (3PG-F 420 ) was discovered, enabling the production and use of F 420 in heterologous hosts. By analyzing the crystal structure of a CofC homolog whose substrate choice leads to formation of 3PG-F 420 , we defined amino acid residues governing the special substrate selectivity. A diagnostic residue enabled reprogramming of the substrate specificity, thus mimicking the evolution of the novel cofactor derivative. Furthermore, a labile reaction product of CofC was revealed that has not been directly detected so far. CofD was shown to provide another layer of specificity of the combined CofC/D reaction, thus controlling the initial substrate choice of CofC. The latter finding resolves a current debate in the literature about the starting point of F 420 biosynthesis in various organisms.


  • Organizational Affiliation

    Junior Research Group Synthetic Microbiology, Leibniz-Institute for Natural Product Research and Infection Biology, Jena, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
3-phospho-D-glycerate guanylyltransferaseA [auth AAA],
B [auth BBB]
243Mycetohabitans rhizoxinica HKI 454Mutation(s): 6
Gene Names: cofCRBRH_02550
EC: 2.7.7.106
UniProt
Find proteins for E5ASS2 (Mycetohabitans rhizoxinica (strain DSM 19002 / CIP 109453 / HKI 454))
Explore E5ASS2
Go to UniProtKB:  E5ASS2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupE5ASS2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
6WI (Subject of Investigation/LOI)
Query on 6WI

Download Ideal Coordinates CCD File
C [auth AAA],
G [auth BBB]
3-(guanosine-5'-diphospho)-D-glycerate
C13 H19 N5 O14 P2
UBONPDGCIQEDRL-QWEIRQIHSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
F [auth AAA],
J [auth BBB],
K [auth BBB]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
MG (Subject of Investigation/LOI)
Query on MG

Download Ideal Coordinates CCD File
D [auth AAA],
E [auth AAA],
H [auth BBB],
I [auth BBB]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.35 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.186
  • Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 57.09α = 90
b = 57.09β = 90
c = 228.97γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research Foundation (DFG)GermanyLA2984-5/1
German Research Foundation (DFG)GermanyLA2984-6/1

Revision History  (Full details and data files)

  • Version 1.0: 2022-02-02
    Type: Initial release
  • Version 1.1: 2022-11-30
    Changes: Database references, Derived calculations
  • Version 1.2: 2022-12-07
    Changes: Database references
  • Version 1.3: 2024-01-31
    Changes: Data collection, Refinement description
