7OG6

Structure of Alternanthera Mosaic VLP by cryoEM


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.30 Å
  • Aggregation State: FILAMENT
  • Reconstruction Method: HELICAL

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

A Replicating Viral Vector Greatly Enhances Accumulation of Helical Virus-Like Particles in Plants.

Thuenemann, E.C.Byrne, M.J.Peyret, H.Saunders, K.Castells-Graells, R.Ferriol, I.Santoni, M.Steele, J.F.C.Ranson, N.A.Avesani, L.Lopez-Moya, J.J.Lomonossoff, G.P.

(2021) Viruses 13

  • DOI: https://doi.org/10.3390/v13050885
  • Primary Citation of Related Structures:
    7OG6

  • PubMed Abstract:

    The production of plant helical virus-like particles (VLPs) via plant-based expression has been problematic with previous studies suggesting that an RNA scaffold may be necessary for their efficient production. To examine this, we compared the accumulation of VLPs from two potexviruses, papaya mosaic virus and alternanthera mosaic virus (AltMV), when the coat proteins were expressed from a replicating potato virus X- based vector (pEff) and a non-replicating vector (pEAQ- HT ). Significantly greater quantities of VLPs could be purified when pEff was used. The pEff system was also very efficient at producing VLPs of helical viruses from different virus families. Examination of the RNA content of AltMV and tobacco mosaic virus VLPs produced from pEff revealed the presence of vector-derived RNA sequences, suggesting that the replicating RNA acts as a scaffold for VLP assembly. Cryo-EM analysis of the AltMV VLPs showed they had a structure very similar to that of authentic potexvirus particles. Thus, we conclude that vectors generating replicating forms of RNA, such as pEff, are very efficient for producing helical VLPs.


  • Organizational Affiliation

    John Innes Centre, Department of Biochemistry and Metabolism, Norwich Research Park, Norwich NR4 7UH, UK.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Coat protein207Potexvirus alternantheraeMutation(s): 0
Gene Names: CP
UniProt
Find proteins for Q52Z61 (Potexvirus alternantherae)
Explore Q52Z61
Go to UniProtKB:  Q52Z61
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ52Z61
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
RNA (5'-R(P*UP*UP*UP*UP*U)-3')B [auth R]5Potexvirus alternantherae
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.30 Å
  • Aggregation State: FILAMENT
  • Reconstruction Method: HELICAL
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.1

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/R00160X/1

Revision History  (Full details and data files)

  • Version 1.0: 2021-06-23
    Type: Initial release
  • Version 1.1: 2024-07-10
    Changes: Data collection, Database references
