7O9Z | pdb_00007o9z

Crystal structure of Human Menin in complex with BD-08

PDB DOI: https://doi.org/10.2210/pdb7O9Z/pdb

Classification: ONCOPROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-04-18 Released: 2022-07-27
Deposition Author(s): Groves, M.R., Gao, K.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.98 Å
R-Value Free:
0.243 (Depositor), 0.240 (DCC)
R-Value Work:
0.211 (Depositor), 0.210 (DCC)
R-Value Observed:
0.213 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of Human Menin in complex with BD-08

Groves, M.R., Gao, K.

To be published.

Macromolecule Content

Total Structure Weight: 55.53 kDa
Atom Count: 3,875
Modeled Residue Count: 462
Deposited Residue Count: 494
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Menin	A	494	Homo sapiens	Mutation(s): 0 Gene Names: MEN1, hCG_2017452
UniProt & NIH Common Fund Data Resources
Find proteins for O00255 (Homo sapiens) Explore O00255 Go to UniProtKB: O00255
PHAROS: O00255 GTEx: ENSG00000133895
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O00255
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
V6N (Subject of Investigation/LOI) Query on V6N Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	(~{E})-2-cyano-3-(2~{H}-indazol-6-yl)-~{N}-(2-morpholin-4-ylethyl)prop-2-enamide C₁₇ H₁₉ N₅ O₂ DCPLXQDYVXXNNX-OQLLNIDSSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain C [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain C [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain C [auth A]	C [auth A], F [auth A], G [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain C [auth A] Focus chain F [auth A] Focus chain G [auth A]
