7NE3 | pdb_00007ne3

Human TET2 in complex with favourable DNA substrate.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.26 Å
  • R-Value Free:
    0.226 (Depositor), 0.230 (DCC)
  • R-Value Work:
    0.175 (Depositor), 0.181 (DCC)
  • R-Value Observed:
    0.177 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7NE3

This is version 1.4 of the entry. See complete history

Literature

Pronounced sequence specificity of the TET enzyme catalytic domain guides its cellular function.

Ravichandran, M.Rafalski, D.Davies, C.I.Ortega-Recalde, O.Nan, X.Glanfield, C.R.Kotter, A.Misztal, K.Wang, A.H.Wojciechowski, M.Razew, M.Mayyas, I.M.Kardailsky, O.Schwartz, U.Zembrzycki, K.Morison, I.M.Helm, M.Weichenhan, D.Jurkowska, R.Z.Krueger, F.Plass, C.Zacharias, M.Bochtler, M.Hore, T.A.Jurkowski, T.P.

(2022) Sci Adv 8: eabm2427-eabm2427

  • DOI: https://doi.org/10.1126/sciadv.abm2427
  • Primary Citation Related Structures:
    7NE3, 7NE6

  • PubMed Abstract:

    TET (ten-eleven translocation) enzymes catalyze the oxidation of 5-methylcytosine bases in DNA, thus driving active and passive DNA demethylation. Here, we report that the catalytic domain of mammalian TET enzymes favor CGs embedded within basic helix-loop-helix and basic leucine zipper domain transcription factor-binding sites, with up to 250-fold preference in vitro. Crystal structures and molecular dynamics calculations show that sequence preference is caused by intrasubstrate interactions and CG flanking sequence indirectly affecting enzyme conformation. TET sequence preferences are physiologically relevant as they explain the rates of DNA demethylation in TET-rescue experiments in culture and in vivo within the zygote and germ line. Most and least favorable TET motifs represent DNA sites that are bound by methylation-sensitive immediate-early transcription factors and octamer-binding transcription factor 4 (OCT4), respectively, illuminating TET function in transcriptional responses and pluripotency support.


  • Organizational Affiliation
    • Department of Anatomy, University of California, San Francisco, 513 Parnassus Avenue, HSW 1301, San Francisco, CA 94143, USA.

Macromolecule Content

  • Total Structure Weight: 59.53 kDa
  • Atom Count: 3,969
  • Modeled Residue Count: 439
  • Deposited Residue Count: 487
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Methylcytosine dioxygenase TET2463Homo sapiensMutation(s): 0
Gene Names: TET2KIAA1546Nbla00191
EC: 1.14.11 (PDB Primary Data), 1.14.11.80 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q6N021 (Homo sapiens)
Explore Q6N021
Go to UniProtKB:  Q6N021
PHAROS:  Q6N021
GTEx:  ENSG00000168769
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6N021
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*AP*CP*AP*GP*GP*(5CM)P*GP*CP*CP*TP*G)-3')
B, C
12synthetic construct
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MES

Query on MES



Download:Ideal Coordinates CCD File
K [auth A]2-(N-MORPHOLINO)-ETHANESULFONIC ACID
C6 H13 N O4 S
SXGZJKUKBWWHRA-UHFFFAOYSA-N
OGA

Query on OGA



Download:Ideal Coordinates CCD File
H [auth A]N-OXALYLGLYCINE
C4 H5 N O5
BIMZLRFONYSTPT-UHFFFAOYSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
D [auth A],
E [auth A],
F [auth A]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
I [auth A],
J [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
FE2

Query on FE2



Download:Ideal Coordinates CCD File
G [auth A]FE (II) ION
Fe
CWYNVVGOOAEACU-UHFFFAOYSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
OGA BindingDB:  7NE3 IC50: min: 9000, max: 1.97e+4 (nM) from 3 assay(s)

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.26 Å
  • R-Value Free:  0.226 (Depositor), 0.230 (DCC)
  • R-Value Work:  0.175 (Depositor), 0.181 (DCC)
  • R-Value Observed: 0.177 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 47.994α = 90
b = 87.711β = 90
c = 260.531γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXdata processing
XDSdata reduction
XDSdata scaling
MxCuBEdata collection

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Foundation for Polish SciencePolandPOIR.04.04.00-00-5D81/17-00

Revision History  (Full details and data files)

  • Version 1.0: 2022-03-02
    Type: Initial release
  • Version 1.1: 2022-08-24
    Changes: Database references, Source and taxonomy, Structure summary
  • Version 1.2: 2022-09-21
    Changes: Database references
  • Version 1.3: 2023-11-22
    Changes: Data collection, Database references
  • Version 1.4: 2024-01-31
    Changes: Refinement description
