7N44

Crystal structure of the SARS-CoV-2 (2019-NCoV) main protease in complex with 5-(3-{3-chloro-5-[(5-methyl-1,3-thiazol-4-yl)methoxy]phenyl}-2-oxo-2H-[1,3'-bipyridin]-5-yl)pyrimidine-2,4(1H,3H)-dione (compound 13)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.94 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.186
  • R-Value Observed: 0.188

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Optimization of Triarylpyridinone Inhibitors of the Main Protease of SARS-CoV-2 to Low-Nanomolar Antiviral Potency.

Zhang, C.H.Spasov, K.A.Reilly, R.A.Hollander, K.Stone, E.A.Ippolito, J.A.Liosi, M.E.Deshmukh, M.G.Tirado-Rives, J.Zhang, S.Liang, Z.Miller, S.J.Isaacs, F.Lindenbach, B.D.Anderson, K.S.Jorgensen, W.L.

(2021) ACS Med Chem Lett 12: 1325-1332

  • DOI: https://doi.org/10.1021/acsmedchemlett.1c00326
  • Primary Citation of Related Structures:
    7N44

  • PubMed Abstract:

    Non-covalent inhibitors of the main protease (M pro ) of SARS-CoV-2 having a pyridinone core were previously reported with IC 50 values as low as 0.018 μM for inhibition of enzymatic activity and EC 50 values as low as 0.8 μM for inhibition of viral replication in Vero E6 cells. The series has now been further advanced by consideration of placement of substituted five-membered-ring heterocycles in the S4 pocket of M pro and N-methylation of a uracil ring. Free energy perturbation calculations provided guidance on the choice of the heterocycles, and protein crystallography confirmed the desired S4 placement. Here we report inhibitors with EC 50 values as low as 0.080 μM, while remdesivir yields values of 0.5-2 μM in side-by-side testing with infectious SARS-CoV-2. A key factor in the improvement is enhanced cell permeability, as reflected in PAMPA measurements. Compounds 19 and 21 are particularly promising as potential therapies for COVID-19, featuring IC 50 values of 0.044-0.061 μM, EC 50 values of ca. 0.1 μM, good aqueous solubility, and no cytotoxicity.


  • Organizational Affiliation

    Department of Chemistry, Yale University, New Haven, Connecticut 06520-8107, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
3C-like proteinase306Severe acute respiratory syndrome coronavirus 2Mutation(s): 0
Gene Names: rep1a-1b
EC: 3.4.22.69
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2)
Explore P0DTD1
Go to UniProtKB:  P0DTD1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0DTD1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
06I (Subject of Investigation/LOI)
Query on 06I

Download Ideal Coordinates CCD File
B [auth A]5-(3-{3-chloro-5-[(5-methyl-1,3-thiazol-4-yl)methoxy]phenyl}-2-oxo-2H-[1,3'-bipyridin]-5-yl)pyrimidine-2,4(1H,3H)-dione
C25 H18 Cl N5 O4 S
RJHJFSODWKKAIP-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.94 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.186
  • R-Value Observed: 0.188
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 116.895α = 90
b = 53.309β = 101.89
c = 44.911γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
XSCALEdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM32136
Other privateUnited StatesYale University School of Medicine CoReCT Pilot Grant

Revision History  (Full details and data files)

  • Version 1.0: 2021-07-21
    Type: Initial release
  • Version 1.1: 2021-09-01
    Changes: Database references
  • Version 1.2: 2023-10-18
    Changes: Data collection, Refinement description
