7MGK

TNNI3K complexed with 1-(3,5-dichloro-4-((6-(methylamino)pyrimidin-4-yl)oxy)phenyl)-3-(3-(trifluoromethyl)phenyl)urea


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.239
  • R-Value Work: 0.196
  • R-Value Observed: 0.198

Starting Model: other
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Identification of Diarylurea Inhibitors of the Cardiac-Specific Kinase TNNI3K by Designing Selectivity Against VEGFR2, p38 alpha , and B-Raf.

Patterson, J.R.Graves, A.P.Stoy, P.Cheung, M.Desai, T.A.Fries, H.Gatto Jr., G.J.Holt, D.A.Shewchuk, L.Totoritis, R.Wang, L.Kallander, L.S.

(2021) J Med Chem 64: 15651-15670

  • DOI: https://doi.org/10.1021/acs.jmedchem.1c00700
  • Primary Citation of Related Structures:
    7MGJ, 7MGK

  • PubMed Abstract:

    A series of diarylurea inhibitors of the cardiac-specific kinase TNNI3K were developed to elucidate the biological function of TNNI3K and evaluate TNNI3K as a therapeutic target for the treatment of cardiovascular diseases. Utilizing a structure-based design, enhancements in kinase selectivity were engineered into the series, capitalizing on the established X-ray crystal structures of TNNI3K, VEGFR2, p38α, and B-Raf. Our efforts culminated in the discovery of an in vivo tool compound 47 (GSK329), which exhibited desirable TNNI3K potency and rat pharmacokinetic properties as well as promising kinase selectivity against VEGFR2 (40-fold), p38α (80-fold), and B-Raf (>200-fold). Compound 47 demonstrated positive cardioprotective outcomes in a mouse model of ischemia/reperfusion cardiac injury, indicating that optimized exemplars from this series, such as 47 , are favorable leads for discovering novel medicines for cardiac diseases.


  • Organizational Affiliation

    Heart Failure Discovery Performance Unit, GlaxoSmithKline, 1250 South Collegeville Road, Collegeville, Pennsylvania 19426, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Serine/threonine-protein kinase TNNI3K
A, B, C, D
311Homo sapiensMutation(s): 0
Gene Names: TNNI3KCARK
EC: 2.7.11.1
UniProt & NIH Common Fund Data Resources
Find proteins for Q59H18 (Homo sapiens)
Explore Q59H18
Go to UniProtKB:  Q59H18
PHAROS:  Q59H18
GTEx:  ENSG00000116783
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ59H18
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.239
  • R-Value Work: 0.196
  • R-Value Observed: 0.198
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 64.673α = 83.28
b = 75.072β = 85.95
c = 95.235γ = 74.79
Software Package:
Software NamePurpose
PHENIXrefinement
SCALEPACKdata scaling
PDB_EXTRACTdata extraction
HKL-2000data reduction
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-11-10
    Type: Initial release
  • Version 1.1: 2021-11-24
    Changes: Database references
  • Version 1.2: 2024-04-03
    Changes: Data collection, Refinement description
