7M9N

HIV-1 Protease (I84V) in Complex with LR3-68

• PDB DOI: https://doi.org/10.2210/pdb7M9N/pdb

• Classification: HYDROLASE/HYDROLASE INHIBITOR
• Organism(s): Human immunodeficiency virus 1
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2021-03-31 Released: 2022-04-20
• Deposition Author(s): Lockbaum, G.J., Schiffer, C.A.
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.82 Å
• R-Value Free: 0.206
• R-Value Work: 0.175
• R-Value Observed: 0.177

Starting Model: experimental

Literature

HIV-1 Protease in Complex with ligands

Lockbaum, G.J., Schiffer, C.A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 22.67 kDa
• Atom Count: 1,798
• Modelled Residue Count: 198
• Deposited Residue Count: 198
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protease	A [auth B], B [auth A]	99	Human immunodeficiency virus 1	Mutation(s): 1  Gene Names: gag-pol EC: 3.4.23.16
UniProt
Find proteins for P12497 (Human immunodeficiency virus type 1 group M subtype B (isolate NY5)) Explore P12497  Go to UniProtKB:  P12497

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
YWM (Subject of Investigation/LOI)	D [auth A]	diethyl [(4-{(2S,3R)-2-[({[(3R,3aS,6aR)-hexahydrofuro[2,3-b]furan-3-yl]oxy}carbonyl)amino]-3-hydroxy-4-[{4-[(1S)-1-hydroxyethyl]benzene-1-sulfonyl}(2-methylpropyl)amino]butyl}phenoxy)methyl]phosphonate C34 H51 N2 O12 P S STYGPCKGGKFCCM-NRCXORKASA-N
SO4	C [auth B], E [auth A], F [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.82 Å
• R-Value Free: 0.206
• R-Value Work: 0.175
• R-Value Observed: 0.177
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.159	α = 90
b = 58.542	β = 90
c = 62.104	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data scaling
PHASER	phasing
PHENIX	refinement
Coot	model building
PDB_EXTRACT	data extraction

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2022-04-20
Deposition Author(s): Lockbaum, G.J., Schiffer, C.A.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	P01-GM109767

Revision History

• Version 1.0: 2022-04-20
  Type: Initial release

• Version 1.1: 2023-10-18
  Changes: Data collection, Refinement description
