7M4U

A. baumannii Ribosome-Eravacycline complex: 30S

  • Classification: RIBOSOME
  • Organism(s): Acinetobacter baumannii AB0057
  • Mutation(s): No

  • Deposited: 2021-03-22 Released: 2021-05-19
  • Deposition Author(s): Morgan, C.E., Yu, E.W.
  • Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.71 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Cryo-EM Determination of Eravacycline-Bound Structures of the Ribosome and the Multidrug Efflux Pump AdeJ of Acinetobacter baumannii.

Zhang, Z.Morgan, C.E.Bonomo, R.A.Yu, E.W.

(2021) mBio 12: e0103121-e0103121

  • DOI: https://doi.org/10.1128/mBio.01031-21
  • Primary Citation of Related Structures:
    7M4P, 7M4Q, 7M4U, 7M4V, 7M4W, 7M4X, 7M4Y, 7M4Z

  • PubMed Abstract:

    Antibiotic-resistant strains of the Gram-negative pathogen Acinetobacter baumannii have emerged as a significant global health threat. One successful therapeutic option to treat bacterial infections has been to target the bacterial ribosome. However, in many cases, multidrug efflux pumps within the bacterium recognize and extrude these clinically important antibiotics designed to inhibit the protein synthesis function of the bacterial ribosome. Thus, multidrug efflux within A. baumannii and other highly drug-resistant strains is a major cause of failure of drug-based treatments of infectious diseases. We here report the first structures of the A cinetobacter d rug e fflux (Ade)J pump in the presence of the antibiotic eravacycline, using single-particle cryo-electron microscopy (cryo-EM). We also describe cryo-EM structures of the eravacycline-bound forms of the A. baumannii ribosome, including the 70S, 50S, and 30S forms. Our data indicate that the AdeJ pump primarily uses hydrophobic interactions to bind eravacycline, while the 70S ribosome utilizes electrostatic interactions to bind this drug. Our work here highlights how an antibiotic can bind multiple bacterial targets through different mechanisms and potentially enables drug optimization by taking advantage of these different modes of ligand binding. IMPORTANCE Acinetobacter baumannii has developed into a highly antibiotic-resistant Gram-negative pathogen. The prevalent AdeJ multidrug efflux pump mediates resistance to different classes of antibiotics known to inhibit the function of the 70S ribosome. Here, we report the first structures of the A. baumannii AdeJ pump, both in the absence and presence of eravacycline. We also describe structures of the A. baumannii ribosome bound by this antibiotic. Our results indicate that AdeJ and the ribosome use very distinct binding modes for drug recognition. Our work will ultimately enable structure-based drug discovery to combat antibiotic-resistant A. baumannii infection.


  • Organizational Affiliation

    Department of Pharmacology, Case Western Reserve University School of Medicine, Cleveland, Ohio, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S2B [auth b]250Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for A0A7U3Y808 (Acinetobacter baumannii (strain AB0057))
Explore A0A7U3Y808
Go to UniProtKB:  A0A7U3Y808
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A7U3Y808
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S3C [auth c]250Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IA33 (Acinetobacter baumannii (strain AB0057))
Explore B7IA33
Go to UniProtKB:  B7IA33
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IA33
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S4D [auth d]208Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IA15 (Acinetobacter baumannii (strain AB0057))
Explore B7IA15
Go to UniProtKB:  B7IA15
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IA15
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S5E [auth e]165Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IA22 (Acinetobacter baumannii (strain AB0057))
Explore B7IA22
Go to UniProtKB:  B7IA22
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IA22
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S6F [auth f]127Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IBC1 (Acinetobacter baumannii (strain AB0057))
Explore B7IBC1
Go to UniProtKB:  B7IBC1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IBC1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S7G [auth g]156Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7I7S0 (Acinetobacter baumannii (strain AB0057))
Explore B7I7S0
Go to UniProtKB:  B7I7S0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7I7S0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S8H [auth h]131Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IA25 (Acinetobacter baumannii (strain AB0057))
Explore B7IA25
Go to UniProtKB:  B7IA25
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IA25
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S9I [auth i]128Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for A0A7U3Y815 (Acinetobacter baumannii (strain AB0057))
Explore A0A7U3Y815
Go to UniProtKB:  A0A7U3Y815
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A7U3Y815
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S10J [auth j]103Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IA40 (Acinetobacter baumannii (strain AB0057))
Explore B7IA40
Go to UniProtKB:  B7IA40
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IA40
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S11K [auth k]128Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IA16 (Acinetobacter baumannii (strain AB0057))
Explore B7IA16
Go to UniProtKB:  B7IA16
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IA16
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S12L [auth l]124Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7I7R9 (Acinetobacter baumannii (strain AB0057))
Explore B7I7R9
Go to UniProtKB:  B7I7R9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7I7R9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S13M [auth m]118Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IA17 (Acinetobacter baumannii (strain AB0057))
Explore B7IA17
Go to UniProtKB:  B7IA17
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IA17
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S14N [auth n]101Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IA26 (Acinetobacter baumannii (strain AB0057))
Explore B7IA26
Go to UniProtKB:  B7IA26
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IA26
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S15O [auth o]89Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7I3U0 (Acinetobacter baumannii (strain AB0057))
Explore B7I3U0
Go to UniProtKB:  B7I3U0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7I3U0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S16P [auth p]101Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for A0A1V3DIZ9 (Acinetobacter baumannii)
Explore A0A1V3DIZ9
Go to UniProtKB:  A0A1V3DIZ9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1V3DIZ9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S17Q [auth q]85Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IA30 (Acinetobacter baumannii (strain AB0057))
Explore B7IA30
Go to UniProtKB:  B7IA30
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IA30
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 18
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S18R [auth r]75Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IBC2 (Acinetobacter baumannii (strain AB0057))
Explore B7IBC2
Go to UniProtKB:  B7IBC2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IBC2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 19
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S19S [auth s]91Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7IA35 (Acinetobacter baumannii (strain AB0057))
Explore B7IA35
Go to UniProtKB:  B7IA35
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7IA35
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 20
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S20T [auth t]88Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7I5N9 (Acinetobacter baumannii (strain AB0057))
Explore B7I5N9
Go to UniProtKB:  B7I5N9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7I5N9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 21
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S21U [auth u]71Acinetobacter baumannii AB0057Mutation(s): 0
UniProt
Find proteins for B7I2K7 (Acinetobacter baumannii (strain AB0057))
Explore B7I2K7
Go to UniProtKB:  B7I2K7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7I2K7
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains LengthOrganismImage
16s Ribosomal RNAA [auth a]1,544Acinetobacter baumannii AB0057
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
YQM (Subject of Investigation/LOI)
Query on YQM

Download Ideal Coordinates CCD File
V [auth a]Eravacycline
C27 H31 F N4 O8
AKLMFDDQCHURPW-ISIOAQNYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
AA [auth a]
AB [auth a]
AC [auth a]
AD [auth e]
BA [auth a]
AA [auth a],
AB [auth a],
AC [auth a],
AD [auth e],
BA [auth a],
BB [auth a],
BC [auth a],
CA [auth a],
CB [auth a],
CC [auth a],
DA [auth a],
DB [auth a],
DC [auth a],
EA [auth a],
EB [auth a],
EC [auth a],
FA [auth a],
FB [auth a],
FC [auth a],
GA [auth a],
GB [auth a],
GC [auth a],
HA [auth a],
HB [auth a],
HC [auth a],
IA [auth a],
IB [auth a],
IC [auth a],
JA [auth a],
JB [auth a],
JC [auth a],
KA [auth a],
KB [auth a],
KC [auth a],
LA [auth a],
LB [auth a],
LC [auth a],
MA [auth a],
MB [auth a],
MC [auth a],
NA [auth a],
NB [auth a],
NC [auth a],
OA [auth a],
OB [auth a],
OC [auth a],
PA [auth a],
PB [auth a],
PC [auth a],
QA [auth a],
QB [auth a],
QC [auth a],
RA [auth a],
RB [auth a],
RC [auth a],
SA [auth a],
SB [auth a],
SC [auth a],
TA [auth a],
TB [auth a],
TC [auth a],
UA [auth a],
UB [auth a],
UC [auth a],
VA [auth a],
VB [auth a],
VC [auth a],
W [auth a],
WA [auth a],
WB [auth a],
WC [auth a],
X [auth a],
XA [auth a],
XB [auth a],
XC [auth a],
Y [auth a],
YA [auth a],
YB [auth a],
YC [auth a],
Z [auth a],
ZA [auth a],
ZB [auth a],
ZC [auth a]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.71 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2021-05-19
    Type: Initial release
  • Version 1.1: 2021-06-09
    Changes: Database references
  • Version 1.2: 2021-07-21
    Changes: Database references
  • Version 1.3: 2024-03-06
    Changes: Data collection, Database references
