7LVH

CRYSTAL STRUCTURE OF AP2 ASSOCIATED KINASE 1 ISOFORM 1 COMPLEXED WITH LIGAND N-[3-METHOXY-4-(1,3-OXAZOL-5-YL)PHENYL]-3-(PROPAN-2-YL)PIPERIDINE-2-CARBOXAMIDE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.299
  • R-Value Work: 0.265
  • R-Value Observed: 0.267

Starting Model: other
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Discovery, Structure-Activity Relationships, and In Vivo Evaluation of Novel Aryl Amides as Brain Penetrant Adaptor Protein 2-Associated Kinase 1 (AAK1) Inhibitors for the Treatment of Neuropathic Pain.

Hartz, R.A.Ahuja, V.T.Nara, S.J.Kumar, C.M.V.Brown, J.M.Bristow, L.J.Rajamani, R.Muckelbauer, J.K.Camac, D.Kiefer, S.E.Hunihan, L.Gulianello, M.Lewis, M.Easton, A.Lippy, J.S.Surti, N.Pattipati, S.N.Dokania, M.Elavazhagan, S.Dandapani, K.Hamman, B.D.Allen, J.Kostich, W.Bronson, J.J.Macor, J.E.Dzierba, C.D.

(2021) J Med Chem 64: 11090-11128

  • DOI: https://doi.org/10.1021/acs.jmedchem.1c00472
  • Primary Citation of Related Structures:
    7LVH, 7LVI

  • PubMed Abstract:

    Effective treatment of chronic pain, in particular neuropathic pain, without the side effects that often accompany currently available treatment options is an area of significant unmet medical need. A phenotypic screen of mouse gene knockouts led to the discovery that adaptor protein 2-associated kinase 1 (AAK1) is a potential therapeutic target for neuropathic pain. The synthesis and optimization of structure-activity relationships of a series of aryl amide-based AAK1 inhibitors led to the identification of 59 , a brain penetrant, AAK1-selective inhibitor that proved to be a valuable tool compound. Compound 59 was evaluated in mice for the inhibition of μ2 phosphorylation. Studies conducted with 59 in pain models demonstrated that this compound was efficacious in the phase II formalin model for persistent pain and the chronic-constriction-injury-induced model for neuropathic pain in rats. These results suggest that AAK1 inhibition is a promising approach for the treatment of neuropathic pain.


  • Organizational Affiliation

    Department of Small Molecule Drug Discovery, Bristol Myers Squibb Company, Research and Development, Wallingford, Connecticut 06492, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
AP2-associated protein kinase 1
A, B
318Mus musculusMutation(s): 0
Gene Names: Aak1Kiaa1048
EC: 2.7.11.1
UniProt & NIH Common Fund Data Resources
Find proteins for Q3UHJ0 (Mus musculus)
Explore Q3UHJ0
Go to UniProtKB:  Q3UHJ0
IMPC:  MGI:1098687
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ3UHJ0
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Binding Affinity Annotations
IDSourceBinding Affinity
YFS BindingDB:  7LVH IC50: min: 12, max: 60 (nM) from 2 assay(s)
YFV BindingDB:  7LVH IC50: 55 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.299
  • R-Value Work: 0.265
  • R-Value Observed: 0.267
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 91.514α = 90
b = 91.514β = 90
c = 172.145γ = 120
Software Package:
Software NamePurpose
d*TREKdata reduction
d*TREKdata scaling
BUSTERrefinement
PDB_EXTRACTdata extraction
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-07-28
    Type: Initial release
  • Version 1.1: 2021-08-04
    Changes: Database references
  • Version 1.2: 2021-08-11
    Changes: Database references
  • Version 1.3: 2021-08-25
    Changes: Database references
  • Version 1.4: 2024-04-03
    Changes: Data collection, Refinement description
