7LSZ

Hsp90a N-terminal inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.188
  • R-Value Work: 0.174
  • R-Value Observed: 0.175

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Selective Inhibition of the Hsp90 alpha Isoform.

Mishra, S.J.Khandelwal, A.Banerjee, M.Balch, M.Peng, S.Davis, R.E.Merfeld, T.Munthali, V.Deng, J.Matts, R.L.Blagg, B.S.J.

(2021) Angew Chem Int Ed Engl 60: 10547-10551

  • DOI: https://doi.org/10.1002/anie.202015422
  • Primary Citation of Related Structures:
    7LSZ, 7LT0

  • PubMed Abstract:

    The 90 kDa heat shock protein (Hsp90) is a molecular chaperone that processes nascent polypeptides into their biologically active conformations. Many of these proteins contribute to the progression of cancer, and consequently, inhibition of the Hsp90 protein folding machinery represents an innovative approach toward cancer chemotherapy. However, clinical trials with Hsp90 N-terminal inhibitors have encountered deleterious side effects and toxicities, which appear to result from the pan-inhibition of all four Hsp90 isoforms. Therefore, the development of isoform-selective Hsp90 inhibitors is sought to delineate the pathological role played by each isoform. Herein, we describe a structure-based approach that was used to design the first Hsp90α-selective inhibitors, which exhibit >50-fold selectivity versus other Hsp90 isoforms.


  • Organizational Affiliation

    Department of Chemistry and Biochemistry, The University of Notre Dame, 305 McCourtney Hall, Notre Dame, IN, 46556, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Heat shock protein HSP 90-alpha293Homo sapiensMutation(s): 0
Gene Names: HSP90AA1HSP90AHSPC1HSPCA
EC: 3.6.4.10
UniProt & NIH Common Fund Data Resources
Find proteins for P07900 (Homo sapiens)
Explore P07900
Go to UniProtKB:  P07900
PHAROS:  P07900
GTEx:  ENSG00000080824
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07900
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ONG (Subject of Investigation/LOI)
Query on ONG

Download Ideal Coordinates CCD File
B [auth A]{3-[(2,3-dihydro-1,4-benzodioxin-6-yl)sulfanyl]-4-hydroxyphenyl}(1,3-dihydro-2H-isoindol-2-yl)methanone
C23 H19 N O4 S
GNTZGEZCMHJEGG-UHFFFAOYSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
ONG BindingDB:  7LSZ Kd: 520 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.188
  • R-Value Work: 0.174
  • R-Value Observed: 0.175
  • Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.761α = 90
b = 89.983β = 90
c = 98.303γ = 90
Software Package:
Software NamePurpose
HKL-2000data scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-03-03
    Type: Initial release
  • Version 1.1: 2021-03-10
    Changes: Database references
  • Version 1.2: 2021-04-07
    Changes: Database references
  • Version 1.3: 2021-05-05
    Changes: Database references
  • Version 1.4: 2023-10-18
    Changes: Advisory, Data collection, Database references, Refinement description
