7LJP | pdb_00007ljp

Structure of Thermotoga maritima SmpB

PDB DOI: https://doi.org/10.2210/pdb7LJP/pdb

Classification: RNA BINDING PROTEIN
Organism(s): Thermotoga maritima MSB8
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-01-29 Released: 2022-02-09
Deposition Author(s): Chan, C.W., Mondragon, A.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.215 (Depositor), 0.216 (DCC)
R-Value Work:
0.184 (Depositor), 0.186 (DCC)
R-Value Observed:
0.186 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of Thermotoga maritima SmpB reveals its C-terminal tail domain in a helical conformation mimicking that of a ribosome-bound state

Chan, C.W., Mondragon, A.

To be published.

Macromolecule Content

Total Structure Weight: 58.35 kDa
Atom Count: 3,704
Modeled Residue Count: 419
Deposited Residue Count: 483
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
SsrA-binding protein	A, B, C	161	Thermotoga maritima MSB8	Mutation(s): 0 Gene Names: smpB, TM_0254
UniProt
Find proteins for P56944 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore P56944 Go to UniProtKB: P56944
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P56944
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain X [auth C] SDF format, chain W [auth C] SDF format, chain P [auth B] SDF format, chain O [auth B] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] MOL2 format, chain X [auth C] MOL2 format, chain W [auth C] MOL2 format, chain P [auth B] MOL2 format, chain O [auth B] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] mmCIF format, chain X [auth C] mmCIF format, chain W [auth C] mmCIF format, chain P [auth B] mmCIF format, chain O [auth B] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A]	I [auth A] J [auth A] K [auth A] O [auth B] P [auth B] I [auth A], J [auth A], K [auth A], O [auth B], P [auth B], W [auth C], X [auth C]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain W [auth C] Focus chain X [auth C] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain W [auth C] Focus chain X [auth C]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain Y [auth C] SDF format, chain S [auth B] SDF format, chain R [auth B] SDF format, chain Q [auth B] SDF format, chain L [auth A] MOL2 format, chain Y [auth C] MOL2 format, chain S [auth B] MOL2 format, chain R [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain L [auth A] mmCIF format, chain Y [auth C] mmCIF format, chain S [auth B] mmCIF format, chain R [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain L [auth A]	L [auth A], Q [auth B], R [auth B], S [auth B], Y [auth C]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain L [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain Y [auth C] Interactions & Density Focus chain L [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain Y [auth C]
DIO (Subject of Investigation/LOI) Query on DIO Download:Ideal Coordinates CCD File SDF format, chain V [auth C] SDF format, chain U [auth C] SDF format, chain T [auth C] SDF format, chain N [auth B] SDF format, chain M [auth B] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain V [auth C] MOL2 format, chain U [auth C] MOL2 format, chain T [auth C] MOL2 format, chain N [auth B] MOL2 format, chain M [auth B] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain V [auth C] mmCIF format, chain U [auth C] mmCIF format, chain T [auth C] mmCIF format, chain N [auth B] mmCIF format, chain M [auth B] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A] E [auth A] F [auth A] G [auth A] H [auth A] D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], M [auth B], N [auth B], T [auth C], U [auth C], V [auth C]	1,4-DIETHYLENE DIOXIDE C₄ H₈ O₂ RYHBNJHYFVUHQT-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain T [auth C] Focus chain U [auth C] Focus chain V [auth C] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain T [auth C] Focus chain U [auth C] Focus chain V [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.215 (Depositor), 0.216 (DCC)
R-Value Work: 0.184 (Depositor), 0.186 (DCC)
R-Value Observed: 0.186 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 92.539	α = 90
b = 92.539	β = 90
c = 307.943	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
REFMAC	refinement
Coot	model building
BUCCANEER	model building
PHASER	phasing
Aimless	data scaling
iMOSFLM	data reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-02-09

Deposition Author(s):

Chan, C.W.

Mondragon, A.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R01 GM058443
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R35 GM118108
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	T32 GM008152
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	T32 GM008382
