7KWD | pdb_00007kwd

Crystal structure of Thermus thermophilus alkaline phosphatase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:
    0.201 (Depositor), 0.201 (DCC)
  • R-Value Work:
    0.163 (Depositor), 0.164 (DCC)
  • R-Value Observed:
    0.165 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7KWD

This is version 1.2 of the entry. See complete history

Literature

Dynamic cross correlation analysis of Thermus thermophilus alkaline phosphatase and determinants of thermostability.

Borges, B.Gallo, G.Coelho, C.Negri, N.Maiello, F.Hardy, L.Wurtele, M.

(2021) Biochim Biophys Acta Gen Subj 1865: 129895-129895

  • DOI: https://doi.org/10.1016/j.bbagen.2021.129895
  • Primary Citation Related Structures:
    7KWD

  • PubMed Abstract:

    Understanding the determinants of protein thermostability is very important both from the theoretical and applied perspective. One emerging view in thermostable enzymes seems to indicate that a salt bridge/charged residue network plays a fundamental role in their thermostability. The structure of alkaline phosphatase (AP) from Thermus thermophilus HB8 was solved by X-ray crystallography at 2.1 Å resolution. The obtained structure was further analyzed by molecular dynamics studies at different temperatures (303 K, 333 K and 363 K) and compared to homologous proteins from the cold-adapted organisms Shewanella sp. and Vibrio strain G15-21. To analyze differences in measures of dynamic variation, several data reduction techniques like principal component analysis (PCA), residue interaction network (RIN) analysis and rotamer analysis were used. Using hierarchical clustering, the obtained results were combined to determine residues showing high degree dynamical variations due to temperature jumps. Furthermore, dynamic cross correlation (DCC) analysis was carried out to characterize networks of charged residues. Top clustered residues showed a higher propensity for thermostabilizing mutations, indicating evolutionary pressure acting on thermophilic organisms. The description of rotamer distributions by Gini coefficients and Kullback-Leibler (KL) divergence both revealed significant correlations with temperature. DCC analysis revealed a significant trend to de-correlation of the movement of charged residues at higher temperatures. The de-correlation of charged residues detected in Thermus thermophilus AP, highlights the importance of dynamic electrostatic network interactions for the thermostability of this enzyme.


  • Organizational Affiliation
    • Department of Science and Technology, Federal University of São Paulo, São José dos Campos, Brazil.

Macromolecule Content

  • Total Structure Weight: 110.32 kDa
  • Atom Count: 7,835
  • Modeled Residue Count: 946
  • Deposited Residue Count: 1,002
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Alkaline phosphatase
A, B
501Thermus thermophilus HB8Mutation(s): 0
Gene Names: TTHB067
UniProt
Find proteins for Q53W95 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q53W95
Go to UniProtKB:  Q53W95
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ53W95
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TLA

Query on TLA



Download:Ideal Coordinates CCD File
C [auth A],
G [auth B]
L(+)-TARTARIC ACID
C4 H6 O6
FEWJPZIEWOKRBE-JCYAYHJZSA-N
ZN
(Subject of Investigation/LOI)

Query on ZN



Download:Ideal Coordinates CCD File
E [auth A],
F [auth A],
I [auth B],
J [auth B]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG
(Subject of Investigation/LOI)

Query on MG



Download:Ideal Coordinates CCD File
D [auth A],
H [auth B]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:  0.201 (Depositor), 0.201 (DCC)
  • R-Value Work:  0.163 (Depositor), 0.164 (DCC)
  • R-Value Observed: 0.165 (Depositor)
Space Group: P 21 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 163.175α = 90
b = 163.175β = 90
c = 163.175γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Sao Paulo Research Foundation (FAPESP)Brazil11/50963
Brazilian National Council for Scientific and Technological Development (CNPq)Brazil448833/2014-0

Revision History  (Full details and data files)

  • Version 1.0: 2021-04-14
    Type: Initial release
  • Version 1.1: 2021-04-28
    Changes: Database references
  • Version 1.2: 2023-10-18
    Changes: Data collection, Database references, Refinement description
