The crystal structure of the I38T mutant PA endonuclease (2009/H1N1/California) in complex with SJ000988558
Cuypers, M.G., Slavish, P.J., Jayaraman, S., White, S.W.To be published.
Experimental Data Snapshot
Starting Model: experimental
View more details
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
Protein PA-X | 197 | Influenza A virus, Influenza A virus (A/Luxembourg/43/2009(H1N1)) This entity is chimeric | Mutation(s): 0  Gene Names: PA-X, PA | ![]() | |
UniProt | |||||
Find proteins for C6H0Y9 (Influenza A virus) Explore C6H0Y9  Go to UniProtKB:  C6H0Y9 | |||||
Entity Groups   | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | C6H0Y9 | ||||
Sequence AnnotationsExpand | |||||
|
Ligands 4 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
QQ4 Query on QQ4 | E [auth A] | Hexa Vinylpyrrolidone K15 C36 H56 N6 O6 OFPQNVWJHZVWCZ-CMPUJJQDSA-N | |||
WTD (Subject of Investigation/LOI) Query on WTD | D [auth A] | 2-(2,6-difluorophenyl)-5-hydroxy-N-[2-(4-hydroxy-3-methoxyphenyl)ethyl]-6-oxo-3,6-dihydropyrimidine-4-carboxamide C20 H17 F2 N3 O5 YORHGKVJYLNOPJ-UHFFFAOYSA-N | |||
SO4 Query on SO4 | F [auth A], G [auth A], H [auth A] | SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L | |||
MN Query on MN | B [auth A], C [auth A] | MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N |
Length ( Å ) | Angle ( ˚ ) |
---|---|
a = 89.173 | α = 90 |
b = 89.173 | β = 90 |
c = 131.846 | γ = 90 |
Software Name | Purpose |
---|---|
PHENIX | refinement |
XDS | data reduction |
Aimless | data scaling |
MOLREP | phasing |
