7K74 | pdb_00007k74

Crystal Structure of Fructose-1,6-bisphosphatase, type I, from Stenotrophomonas maltophilia K279a

PDB DOI: https://doi.org/10.2210/pdb7K74/pdb

Classification: HYDROLASE
Organism(s): Stenotrophomonas maltophilia K279a
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2020-09-22 Released: 2020-10-21
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free:
0.251 (Depositor), 0.250 (DCC)
R-Value Work:
0.213 (Depositor), 0.214 (DCC)
R-Value Observed:
0.214 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7K74

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of Fructose-1,6-bisphosphatase, type I, from Stenotrophomonas maltophilia K279a

Abendroth, J., Horanyi, P.S., Lorimer, D.D., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 150.13 kDa
Atom Count: 10,258
Modeled Residue Count: 1,294
Deposited Residue Count: 1,368
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fructose-1,6-bisphosphatase class 1	A, B, C, D	342	Stenotrophomonas maltophilia K279a	Mutation(s): 0 Gene Names: fbp, Smlt0047 EC: 3.1.3.11
UniProt
Find proteins for B2FU10 (Stenotrophomonas maltophilia (strain K279a)) Explore B2FU10 Go to UniProtKB: B2FU10
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	B2FU10
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain G [auth C] SDF format, chain H [auth D] SDF format, chain F [auth B] SDF format, chain E [auth A] MOL2 format, chain G [auth C] MOL2 format, chain H [auth D] MOL2 format, chain F [auth B] MOL2 format, chain E [auth A] mmCIF format, chain G [auth C] mmCIF format, chain H [auth D] mmCIF format, chain F [auth B] mmCIF format, chain E [auth A]	E [auth A], F [auth B], G [auth C], H [auth D]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free: 0.251 (Depositor), 0.250 (DCC)
R-Value Work: 0.213 (Depositor), 0.214 (DCC)
R-Value Observed: 0.214 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 76.04	α = 90
b = 125.73	β = 90
c = 158.45	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
MoRDa	phasing
PHENIX	model building
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2020-10-21

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History (Full details and data files)

Version 1.0: 2020-10-21
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Database references, Refinement description
