7F0W | pdb_00007f0w

Crystal structure of KRAS-G12D bound to GDP with switch 1 open conformation

PDB DOI: https://doi.org/10.2210/pdb7F0W/pdb

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2021-06-07 Released: 2021-06-23
Deposition Author(s): Zhang, F.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.39 Å
R-Value Free:
0.190 (Depositor), 0.188 (DCC)
R-Value Work:
0.171 (Depositor), 0.174 (DCC)
R-Value Observed:
0.172 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7F0W

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of KRAS-G12D bound to GDP with switch 1 open conformation

Zhang, F.

To be published.

Macromolecule Content

Total Structure Weight: 19.75 kDa
Atom Count: 1,479
Modeled Residue Count: 167
Deposited Residue Count: 169
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isoform 2B of GTPase KRas	A	169	Homo sapiens	Mutation(s): 1 Gene Names: KRAS, KRAS2, RASK2 EC: 3.6.5.2
UniProt & NIH Common Fund Data Resources
Find proteins for P01116 (Homo sapiens) Explore P01116 Go to UniProtKB: P01116
PHAROS: P01116 GTEx: ENSG00000133703
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P01116
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GDP (Subject of Investigation/LOI) Query on GDP Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	GUANOSINE-5'-DIPHOSPHATE C₁₀ H₁₅ N₅ O₁₁ P₂ QGWNDRXFNXRZMB-UUOKFMHZSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.39 Å
R-Value Free: 0.190 (Depositor), 0.188 (DCC)
R-Value Work: 0.171 (Depositor), 0.174 (DCC)
R-Value Observed: 0.172 (Depositor)

Space Group: P 3 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 78.315	α = 90
b = 78.315	β = 90
c = 55.929	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2021-06-23

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2021-06-23
Type: Initial release
Version 1.1: 2023-11-29
Changes: Data collection, Database references, Refinement description
