7EN1 | pdb_00007en1

Pyochelin synthetase, a dimeric nonribosomal peptide synthetase elongation module-after-condensation


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.47 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7EN1

This is version 1.1 of the entry. See complete history

Literature

Catalytic trajectory of a dimeric nonribosomal peptide synthetase subunit with an inserted epimerase domain.

Wang, J.Li, D.Chen, L.Cao, W.Kong, L.Zhang, W.Croll, T.Deng, Z.Liang, J.Wang, Z.

(2022) Nat Commun 13: 592-592

  • DOI: https://doi.org/10.1038/s41467-022-28284-x
  • Primary Citation Related Structures:
    7EMY, 7EN1, 7EN2

  • PubMed Abstract:

    Nonribosomal peptide synthetases (NRPSs) are modular assembly-line megaenzymes that synthesize diverse metabolites with wide-ranging biological activities. The structural dynamics of synthetic elongation has remained unclear. Here, we present cryo-EM structures of PchE, an NRPS elongation module, in distinct conformations. The domain organization reveals a unique "H"-shaped head-to-tail dimeric architecture. The capture of both aryl and peptidyl carrier protein-tethered substrates and intermediates inside the heterocyclization domain and L-cysteinyl adenylate in the adenylation domain illustrates the catalytic and recognition residues. The multilevel structural transitions guided by the adenylation C-terminal subdomain in combination with the inserted epimerase and the conformational changes of the heterocyclization tunnel are controlled by two residues. Moreover, we visualized the direct structural dynamics of the full catalytic cycle from thiolation to epimerization. This study establishes the catalytic trajectory of PchE and sheds light on the rational re-engineering of domain-inserted dimeric NRPSs for the production of novel pharmaceutical agents.


  • Organizational Affiliation
    • State Key Laboratory of Microbial Metabolism, Joint International Research Laboratory of Metabolic & Developmental Sciences, and School of Life Science & Biotechnology, Shanghai Jiao Tong University, Shanghai, China.

Macromolecule Content

  • Total Structure Weight: 319.59 kDa
  • Atom Count: 20,443
  • Modeled Residue Count: 2,654
  • Deposited Residue Count: 2,910
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Dihydroaeruginoic acid synthetase
A, B
1,455Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: pchEPA4226
EC: 6.2.1.69
UniProt
Find proteins for G3XCV2 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore G3XCV2
Go to UniProtKB:  G3XCV2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG3XCV2
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PNS

Query on PNS



Download:Ideal Coordinates CCD File
C [auth A],
H [auth B]
4'-PHOSPHOPANTETHEINE
C11 H23 N2 O7 P S
JDMUPRLRUUMCTL-VIFPVBQESA-N
AMP

Query on AMP



Download:Ideal Coordinates CCD File
F [auth A],
K [auth B]
ADENOSINE MONOPHOSPHATE
C10 H14 N5 O7 P
UDMBCSSLTHHNCD-KQYNXXCUSA-N
J9F
(Subject of Investigation/LOI)

Query on J9F



Download:Ideal Coordinates CCD File
D [auth A](4S)-2-(2-hydroxyphenyl)-4,5-dihydro-1,3-thiazole-4-carboxylic acid
C10 H9 N O3 S
CECDPVOEINSAQG-SSDOTTSWSA-N
SAL

Query on SAL



Download:Ideal Coordinates CCD File
I [auth B]2-HYDROXYBENZOIC ACID
C7 H6 O3
YGSDEFSMJLZEOE-UHFFFAOYSA-N
CYS

Query on CYS



Download:Ideal Coordinates CCD File
G [auth A],
L [auth B]
CYSTEINE
C3 H7 N O2 S
XUJNEKJLAYXESH-REOHCLBHSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
E [auth A],
J [auth B]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.47 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (NSF, China)China91753123

Revision History  (Full details and data files)

  • Version 1.0: 2021-12-22
    Type: Initial release
  • Version 1.1: 2023-07-05
    Changes: Database references
