7EDW | pdb_00007edw

DNA duplex containing T-T base pairs in complex with Au(III)

PDB DOI: https://doi.org/10.2210/pdb7EDW/pdb
NAKB: 7EDW

Classification: DNA
Organism(s): synthetic construct
Mutation(s): No

Deposited: 2021-03-17 Released: 2022-03-23
Deposition Author(s): Kondo, J., Iwase, E.
Funding Organization(s): Ministry of Education, Culture, Sports, Science and Technology (Japan)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.186 (Depositor), 0.187 (DCC)
R-Value Work:
0.165 (Depositor), 0.167 (DCC)
R-Value Observed:
0.167 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7EDW

This is version 1.1 of the entry. See complete history.

Literature

DNA duplex containing T-T base pairs in complex with Au(III)

Kondo, J., Iwase, E.

To be published.

Macromolecule Content

Total Structure Weight: 7.9 kDa
Atom Count: 543
Modeled Residue Count: 24
Deposited Residue Count: 24
Unique nucleic acid chains: 1

Macromolecules

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 1
DNA (5'-D(GPGPAPCPCPTPTPGPGPTPCPC)-3')	A, B	12	synthetic construct
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
AU (Subject of Investigation/LOI) Query on AU Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth B]	C [auth A], D [auth A], E [auth B]	GOLD ION Au ZBKIUFWVEIBQRT-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.186 (Depositor), 0.187 (DCC)
R-Value Work: 0.165 (Depositor), 0.167 (DCC)
R-Value Observed: 0.167 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 37.076	α = 90
b = 42.8	β = 90
c = 67.383	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
XDS	data reduction
AutoSol	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-03-23

Deposition Author(s):

Funding Organization	Location	Grant Number
Ministry of Education, Culture, Sports, Science and Technology (Japan)	Japan	24245037

Revision History (Full details and data files)

Version 1.0: 2022-03-23
Type: Initial release
Version 1.1: 2024-05-29
Changes: Data collection
