7DUC | pdb_00007duc

Crystal Structure of cyto WalK

PDB DOI: https://doi.org/10.2210/pdb7DUC/pdb

Classification: TRANSFERASE
Organism(s): Staphylococcus aureus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2021-01-08 Released: 2022-01-19
Deposition Author(s): Huang, W.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.56 Å
R-Value Free:
0.240 (Depositor), 0.238 (DCC)
R-Value Work:
0.195 (Depositor), 0.195 (DCC)
R-Value Observed:
0.197 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7DUC

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of cyto WalK

Huang, W.

To be published.

Macromolecule Content

Total Structure Weight: 28.98 kDa
Atom Count: 1,798
Modeled Residue Count: 216
Deposited Residue Count: 252
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sensor protein kinase WalK	A, B	126	Staphylococcus aureus	Mutation(s): 0 Gene Names: walK, vicK, yycG EC: 2.7.13.3
UniProt
Find proteins for Q2G2U4 (Staphylococcus aureus (strain NCTC 8325 / PS 47)) Explore Q2G2U4 Go to UniProtKB: Q2G2U4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q2G2U4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.56 Å
R-Value Free: 0.240 (Depositor), 0.238 (DCC)
R-Value Work: 0.195 (Depositor), 0.195 (DCC)
R-Value Observed: 0.197 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.725	α = 90
b = 60.201	β = 90
c = 81.306	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2022-01-19

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2022-01-19
Type: Initial release
Version 1.1: 2023-11-29
Changes: Data collection, Refinement description
