7CNB

Crystal structure of Gp16 C-terminal domain from Bacillus virus phi29


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.32 Å
  • R-Value Free: 0.271
  • R-Value Work: 0.249
  • R-Value Observed: 0.249

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structural Insights into gp16 ATPase in the Bacteriophage φ29 DNA Packaging Motor.

Saeed, A.F.U.H.Chan, C.Guan, H.Gong, B.Guo, P.Cheng, X.Ouyang, S.

(2021) Biochemistry 60: 886-897

  • DOI: https://doi.org/10.1021/acs.biochem.0c00935
  • Primary Citation of Related Structures:
    7CNB

  • PubMed Abstract:

    Biological motors, ubiquitous in living systems, convert chemical energy into different kinds of mechanical motions critical to cellular functions. Gene product 16 (gp16) in bacteriophage ϕ29 is among the most powerful biomotors known, which adopts a multisubunit ring-shaped structure and hydrolyzes ATP to package double-stranded DNA (dsDNA) into a preformed procapsid. Here we report the crystal structure of the C-terminal domain of gp16 (gp16-CTD). Structure-based alignment and molecular dynamics simulations revealed an essential binding surface of gp16-CTD for prohead RNA, a unique component of the motor complex. Furthermore, our simulations highlighted a dynamic interplay between the N-terminal domain and the CTD of gp16, which may play a role in driving movement of DNA into the procapsid. Lastly, we assembled an atomic structural model of the complete ϕ29 dsDNA packaging motor complex by integrating structural and experimental data from multiple sources. Collectively, our findings provided a refined inchworm-revolution model for dsDNA translocation in bacteriophage ϕ29 and suggested how the individual domains of gp16 work together to power such translocation.


  • Organizational Affiliation

    The Key Laboratory of Innate Immune Biology of Fujian Province, Provincial University Key Laboratory of Cellular Stress Response and Metabolic Regulation, Biomedical Research Center of South China, Key Laboratory of OptoElectronic Science and Technology for Medicine of Ministry of Education, College of Life Sciences, Fujian Normal University, Fuzhou 350117, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA packaging protein107Salasvirus phi29Mutation(s): 0
Gene Names: 16
EC: 3.6.4
UniProt
Find proteins for P11014 (Bacillus phage phi29)
Explore P11014
Go to UniProtKB:  P11014
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP11014
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.32 Å
  • R-Value Free: 0.271
  • R-Value Work: 0.249
  • R-Value Observed: 0.249
  • Space Group: P 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.682α = 90
b = 42.682β = 90
c = 135.856γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
HKL-2000data collection
Cootmodel building
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-03-24
    Type: Initial release
  • Version 1.1: 2021-03-31
    Changes: Database references
  • Version 1.2: 2021-04-07
    Changes: Database references
  • Version 1.3: 2024-03-27
    Changes: Data collection, Database references
