7CM1

Neuraminidase from the Wuhan Asiatic toad influenza virus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.14 Å
  • R-Value Free: 0.280
  • R-Value Work: 0.220
  • R-Value Observed: 0.223

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Lattice-translocation defects in specific crystals of the catalytic head domain of influenza neuraminidase.

Li, L.Dai, S.Gao, G.F.Wang, J.

(2020) Acta Crystallogr D Struct Biol 76: 1057-1064

  • DOI: https://doi.org/10.1107/S2059798320011869
  • Primary Citation of Related Structures:
    7CM1

  • PubMed Abstract:

    Neuraminidase (NA) inhibitors are one of the two major classes of antivirals available for the treatment and prevention of influenza. X-ray crystal structure determination of NA head domains and their complexes with various inhibitors are of importance for the design and optimization of anti-influenza drugs. However, the globular tetrameric properties of NA head domains may produce crystals with pathological imperfections, lattice-translocation defects, making structure determination no longer straightforward. In this report, using a crystal of the NA head domain from the Wuhan Asiatic toad influenza virus as an example, the identification and solution of this type of crystal pathology are presented. Furthermore, its underlying mechanism of formation is explored.


  • Organizational Affiliation

    CAS Key Laboratory of Pathogenic Microbiology and Immunology, Institute of Microbiology, Chinese Academy of Sciences, Beijing 100101, People's Republic of China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
NeuraminidaseA [auth B],
B [auth A]
387Wuhan asiatic toad influenza virusMutation(s): 0
Gene Names: NA
EC: 3.2.1.18
UniProt
Find proteins for A0A2P1GNT2 (Wuhan asiatic toad influenza virus)
Explore A0A2P1GNT2
Go to UniProtKB:  A0A2P1GNT2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A2P1GNT2
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.14 Å
  • R-Value Free: 0.280
  • R-Value Work: 0.220
  • R-Value Observed: 0.223
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 119.966α = 90
b = 143.148β = 90
c = 120.097γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

  • Released Date: 2020-11-18
  • Deposition Author(s): Wang, J.

Revision History  (Full details and data files)

  • Version 1.0: 2020-11-18
    Type: Initial release
  • Version 1.1: 2023-11-29
    Changes: Data collection, Database references, Refinement description
  • Version 1.2: 2024-10-23
    Changes: Structure summary
