7BAG | pdb_00007bag

C3b in complex with CP40


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.225 (Depositor), 0.198 (DCC)
  • R-Value Work:
    0.194 (Depositor), 0.197 (DCC)
  • R-Value Observed:
    0.196 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7BAG

This is version 2.1 of the entry. See complete history

Literature

Insight into mode-of-action and structural determinants of the compstatin family of clinical complement inhibitors.

Lamers, C.Xue, X.Smiesko, M.van Son, H.Wagner, B.Berger, N.Sfyroera, G.Gros, P.Lambris, J.D.Ricklin, D.

(2022) Nat Commun 13: 5519-5519

  • DOI: https://doi.org/10.1038/s41467-022-33003-7
  • Primary Citation Related Structures:
    7BAG

  • PubMed Abstract:

    With the addition of the compstatin-based complement C3 inhibitor pegcetacoplan, another class of complement targeted therapeutics have recently been approved. Moreover, compstatin derivatives with enhanced pharmacodynamic and pharmacokinetic profiles are in clinical development (e.g., Cp40/AMY-101). Despite this progress, the target binding and inhibitory modes of the compstatin family remain incompletely described. Here, we present the crystal structure of Cp40 complexed with its target C3b at 2.0-Å resolution. Structure-activity-relationship studies rationalize the picomolar affinity and long target residence achieved by lead optimization, and reveal a role for structural water in inhibitor binding. We provide explanations for the narrow species specificity of this drug class and demonstrate distinct target selection modes between clinical compstatin derivatives. Functional studies provide further insight into physiological complement activation and corroborate the mechanism of its compstatin-mediated inhibition. Our study may thereby guide the application of existing and development of next-generation compstatin analogs.


  • Organizational Affiliation
    • Department of Pharmaceutical Sciences, University of Basel, Klingelbergstrasse 50, 4056, Basel, Switzerland.

Macromolecule Content

  • Total Structure Weight: 178.33 kDa
  • Atom Count: 13,417
  • Modeled Residue Count: 1,569
  • Deposited Residue Count: 1,574
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Complement C3645Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P01024 (Homo sapiens)
Explore P01024
Go to UniProtKB:  P01024
PHAROS:  P01024
GTEx:  ENSG00000125730
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01024
Glycosylation
Glycosylation Sites: 1Go to GlyGen: P01024-1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Complement C3915Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P01024 (Homo sapiens)
Explore P01024
Go to UniProtKB:  P01024
PHAROS:  P01024
GTEx:  ENSG00000125730
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01024
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:  Sequence   |   3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Compstatin CP4014synthetic constructMutation(s): 0

Oligosaccharides

Help
Entity ID: 4
MoleculeChains Length2D Diagram GlycosylationD Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
D
2N-Glycosylation
Glycosylation Resources
GlyTouCan: G42666HT
GlyCosmos: G42666HT
GlyGen: G42666HT

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PEG

Query on PEG



Download:Ideal Coordinates CCD File
F [auth A],
G [auth A],
I [auth B],
J [auth B],
K [auth B]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
ACM

Query on ACM



Download:Ideal Coordinates CCD File
H [auth B]ACETAMIDE
C2 H5 N O
DLFVBJFMPXGRIB-UHFFFAOYSA-N
CA

Query on CA



Download:Ideal Coordinates CCD File
E [auth A]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
NH2

Query on NH2



Download:Ideal Coordinates CCD File
L [auth C]AMINO GROUP
H2 N
QGZKDVFQNNGYKY-UHFFFAOYSA-N
Modified Residues  3 Unique
IDChains TypeFormula2D DiagramParent
DTY
Query on DTY
C
D-PEPTIDE LINKINGC9 H11 N O3

--

EXL
Query on EXL
C
L-PEPTIDE LINKINGC12 H14 N2 O2TRP
IML
Query on IML
C
L-PEPTIDE LINKINGC7 H15 N O2ILE
SAR
Query on SAR
C
PEPTIDE LINKINGC3 H7 N O2GLY

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.225 (Depositor), 0.198 (DCC)
  • R-Value Work:  0.194 (Depositor), 0.197 (DCC)
  • R-Value Observed: 0.196 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 101.508α = 90
b = 90.528β = 108.84
c = 140.093γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PDB_EXTRACTdata extraction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Swiss National Science FoundationSwitzerland31003A_176104
Netherlands Organisation for Scientific Research (NWO)Netherlands700.54.304
European Research Council (ERC)Netherlands233229
European Communitys Seventh Framework ProgrammeNetherlands283570

Revision History  (Full details and data files)

  • Version 1.0: 2022-01-12
    Type: Initial release
  • Version 1.1: 2023-03-01
    Changes: Database references
  • Version 2.0: 2023-11-15
    Changes: Atomic model, Data collection, Derived calculations
  • Version 2.1: 2024-02-07
    Changes: Refinement description
