7AYP | pdb_00007ayp

Structure of a GH11 domain refined from the X-ray diffraction data of a GH11-CBM36-1 crystal.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:
    0.187 (Depositor), 0.188 (DCC)
  • R-Value Work:
    0.171 (Depositor)
  • R-Value Observed:
    0.172 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7AYP

This is version 1.2 of the entry. See complete history

Literature

Structural and biophysical characterization of the multidomain xylanase Xyl.

Anye, V.Kruger, R.F.Schubert, W.D.

(2022) PLoS One 17: e0269188-e0269188

  • DOI: https://doi.org/10.1371/journal.pone.0269188
  • Primary Citation Related Structures:
    7AX7, 7AY3, 7AYP, 7ZSZ

  • PubMed Abstract:

    The depletion of fossil fuels, associated pollution, and resulting health hazards are of concern worldwide. Woody biomass constitutes an alternative source of cleaner and renewable energy. The efficient use of woody biomass depends on xylan depolymerisation as the endo-β-1,4-xylopyranosyl homopolymer is the main component of hemicellulose, the second most abundant component of wood. Xylan depolymerisation is achieved by hemicellulolytic xylanases of glycoside hydrolase (GH) families 5, 8, 10, 11, 30 and 43 of the CAZY database. We analysed a multidomain xylanase (Xyl) from the hindgut metagenome of the snouted harvester termite Trinervitermes trinervoides that releases xylobiose and xylotriose from beech and birch xylan and wheat arabinoxylan. The four domains of Xyl include an N-terminal GH11 xylanase domain, two family 36-like carbohydrate-binding domains CBM36-1 and 2, and a C-terminal CE4 esterase domain. Previous analyses indicated that CBM36-1 deletion slightly increased GH11 catalysis at low pH whereas removal of both CBMs decreased xylanase activity at 60°C from 90 to 56%. Possible cooperativity between the domains suggested by these observations was explored. A crystal structure of the two-domain construct, GH11-CBM36-1, confirmed the structure of the GH11 domain whereas the CBM36-1 domain lacked electron density, possibly indicating a random orientation of the CBM36-1 domain around the GH11 domain. Isothermal titration calorimetry (ITC) experiments similarly did not indicate specific interactions between the individual domains of Xyl supporting a "beads-on-a-string" model for Xyl domains.


  • Organizational Affiliation
    • Department of Biochemistry, Genetics and Microbiology, Faculty of Natural and Agricultural Sciences, University of Pretoria, Pretoria, South Africa.

Macromolecule Content

  • Total Structure Weight: 46.59 kDa
  • Atom Count: 1,743
  • Modeled Residue Count: 204
  • Deposited Residue Count: 436
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Endo-1,4-beta-xylanase436uncultured bacteriumMutation(s): 0
EC: 3.2.1.8
UniProt
Find proteins for A0ACD6B8V2 (uncultured bacterium)
Explore A0ACD6B8V2
Go to UniProtKB:  A0ACD6B8V2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ACD6B8V2
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:  0.187 (Depositor), 0.188 (DCC)
  • R-Value Work:  0.171 (Depositor)
  • R-Value Observed: 0.172 (Depositor)
Space Group: P 63
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 108.216α = 90
b = 108.216β = 90
c = 54.228γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Research Foundation in South AfricaSouth Africa--

Revision History  (Full details and data files)

  • Version 1.0: 2020-11-25
    Type: Initial release
  • Version 1.1: 2022-06-29
    Changes: Database references
  • Version 1.2: 2024-01-31
    Changes: Data collection, Refinement description
