7AOZ | pdb_00007aoz

Atomic structure of the poxvirus transcription initiation complex in conformation 1


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.85 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7AOZ

This is version 1.3 of the entry. See complete history

Literature

Structural basis of the complete poxvirus transcription initiation process.

Grimm, C.Bartuli, J.Boettcher, B.Szalay, A.A.Fischer, U.

(2021) Nat Struct Mol Biol 28: 779-788

  • DOI: https://doi.org/10.1038/s41594-021-00655-w
  • Primary Citation Related Structures:
    7AMV, 7AOF, 7AOH, 7AOZ, 7AP8, 7AP9

  • PubMed Abstract:

    Poxviruses express their genes in the cytoplasm of infected cells using a virus-encoded multi-subunit polymerase (vRNAP) and unique transcription factors. We present cryo-EM structures that uncover the complete transcription initiation phase of the poxvirus vaccinia. In the pre-initiation complex, the heterodimeric early transcription factor VETFs/l adopts an arc-like shape spanning the polymerase cleft and anchoring upstream and downstream promoter elements. VETFI emerges as a TBP-like protein that inserts asymmetrically into the DNA major groove, triggers DNA melting, ensures promoter recognition and enforces transcription directionality. The helicase VETFs fosters promoter melting and the phospho-peptide domain (PPD) of vRNAP subunit Rpo30 enables transcription initiation. An unprecedented upstream promoter scrunching mechanism assisted by the helicase NPH-I probably fosters promoter escape and transition into elongation. Our structures shed light on unique mechanisms of poxviral gene expression and aid the understanding of thus far unexplained universal principles in transcription.


  • Organizational Affiliation
    • Department of Biochemistry and Cancer Therapy Research Center (CTRC), Theodor Boveri-Institute, University of Würzburg, Würzburg, Germany. clemens.grimm@biozentrum.uni-wuerzburg.de.

Macromolecule Content

  • Total Structure Weight: 543.89 kDa
  • Atom Count: 31,512
  • Modeled Residue Count: 3,824
  • Deposited Residue Count: 4,507
  • Unique protein chains: 9
  • Unique nucleic acid chains: 3

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase 147 kDa polypeptide1,286Vaccinia virus GLV-1h68Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q1PIV1 (Vaccinia virus)
Explore Q1PIV1
Go to UniProtKB:  Q1PIV1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ1PIV1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase1,164Vaccinia virus GLV-1h68Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q49PH2 (Vaccinia virus (strain LC16m0))
Explore Q49PH2
Go to UniProtKB:  Q49PH2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ49PH2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase 35 kDa subunit305Vaccinia virus GLV-1h68Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q49PG1 (Vaccinia virus (strain LC16m0))
Explore Q49PG1
Go to UniProtKB:  Q49PG1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ49PG1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunitD [auth E]185Vaccinia virus GLV-1h68Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for A4GDF1 (Vaccinia virus (strain Lister))
Explore A4GDF1
Go to UniProtKB:  A4GDF1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA4GDF1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase 19 kDa subunitE [auth F]164Vaccinia virus GLV-1h68Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q49QC8 (Vaccinia virus (strain LC16m8))
Explore Q49QC8
Go to UniProtKB:  Q49QC8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ49QC8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 6
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase 18 kDa subunitF [auth G]161Vaccinia virus GLV-1h68Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q49PL6 (Vaccinia virus (strain LC16m0))
Explore Q49PL6
Go to UniProtKB:  Q49PL6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ49PL6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 7
MoleculeChains  Sequence LengthOrganismDetailsImage
Protein H4G [auth I]795Vaccinia virus GLV-1h68Mutation(s): 0
UniProt
Find proteins for Q1PIU7 (Vaccinia virus)
Explore Q1PIU7
Go to UniProtKB:  Q1PIU7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ1PIU7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 8
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase 7 kDa subunitH [auth J]63Vaccinia virus GLV-1h68Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q49QI2 (Vaccinia virus (strain LC16m8))
Explore Q49QI2
Go to UniProtKB:  Q49QI2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ49QI2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 11
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase 30 kDa polypeptideK [auth S]259Vaccinia virus GLV-1h68Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for H2DZ00 (Vaccinia virus)
Explore H2DZ00
Go to UniProtKB:  H2DZ00
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupH2DZ00
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 9
MoleculeChains LengthOrganismImage
Synthetic promoter DNA oligomer, non-template strandI [auth N]60Vaccinia virus GLV-1h68
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 10
MoleculeChains LengthOrganismImage
RNA (5'-R(P*AP*UP*AP*AP*A)-3')J [auth P]5Vaccinia virus GLV-1h68
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 12
MoleculeChains LengthOrganismImage
Synthetic promoter DNA oligomer, template strandL [auth T]60Vaccinia virus GLV-1h68
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.85 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research Foundation (DFG)GermanyFi-573/20-1

Revision History  (Full details and data files)

  • Version 1.0: 2021-10-06
    Type: Initial release
  • Version 1.1: 2021-10-13
    Changes: Data collection, Database references
  • Version 1.2: 2021-10-20
    Changes: Data collection, Database references
  • Version 1.3: 2024-10-16
    Changes: Data collection, Structure summary
