6ZBV

Inward-open structure of human glycine transporter 1 in complex with a benzoylisoindoline inhibitor and sybody Sb_GlyT1#7


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.40 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.214
  • R-Value Observed: 0.217

Starting Models: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Structural insights into the inhibition of glycine reuptake.

Shahsavar, A.Stohler, P.Bourenkov, G.Zimmermann, I.Siegrist, M.Guba, W.Pinard, E.Sinning, S.Seeger, M.A.Schneider, T.R.Dawson, R.J.P.Nissen, P.

(2021) Nature 591: 677-681

  • DOI: https://doi.org/10.1038/s41586-021-03274-z
  • Primary Citation of Related Structures:
    6ZBV, 6ZPL

  • PubMed Abstract:

    The human glycine transporter 1 (GlyT1) regulates glycine-mediated neuronal excitation and inhibition through the sodium- and chloride-dependent reuptake of glycine 1-3 . Inhibition of GlyT1 prolongs neurotransmitter signalling, and has long been a key strategy in the development of therapies for a broad range of disorders of the central nervous system, including schizophrenia and cognitive impairments 4 . Here, using a synthetic single-domain antibody (sybody) and serial synchrotron crystallography, we have determined the structure of GlyT1 in complex with a benzoylpiperazine chemotype inhibitor at 3.4 Å resolution. We find that the inhibitor locks GlyT1 in an inward-open conformation and binds at the intracellular gate of the release pathway, overlapping with the glycine-release site. The inhibitor is likely to reach GlyT1 from the cytoplasmic leaflet of the plasma membrane. Our results define the mechanism of inhibition and enable the rational design of new, clinically efficacious GlyT1 inhibitors.


  • Organizational Affiliation

    Danish Research Institute of Translational Neuroscience-DANDRITE, Nordic EMBL Partnership for Molecular Medicine, Department of Molecular Biology and Genetics, Aarhus University, Aarhus, Denmark.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Sodium- and chloride-dependent glycine transporter 1,Sodium- and chloride-dependent glycine transporter 1577Homo sapiensMutation(s): 4
Gene Names: SLC6A9
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P48067 (Homo sapiens)
Explore P48067
Go to UniProtKB:  P48067
PHAROS:  P48067
GTEx:  ENSG00000196517
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP48067
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Sybody Sb_GlyT1#7120unidentifiedMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
QET
Query on QET

Download Ideal Coordinates CCD File
C [auth A][5-fluoranyl-6-(oxan-4-yloxy)-1,3-dihydroisoindol-2-yl]-[5-methylsulfonyl-2-[2,2,3,3,3-pentakis(fluoranyl)propoxy]phenyl]methanone
C24 H23 F6 N O6 S
FARKUFWPLXRSDR-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.40 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.214
  • R-Value Observed: 0.217
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 65.17α = 90
b = 58.14β = 100.38
c = 122.31γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
PDB_EXTRACTdata extraction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Novo Nordisk FoundationDenmark--
LundbeckfondenDenmark--
RocheSwitzerland--
EIPOD fellowship under Marie Sklodowska-Curie Actions COFUNDGermany664726

Revision History  (Full details and data files)

  • Version 1.0: 2021-03-17
    Type: Initial release
  • Version 1.1: 2021-04-07
    Changes: Database references
  • Version 1.2: 2024-01-24
    Changes: Data collection, Database references, Refinement description
  • Version 1.3: 2024-11-20
    Changes: Structure summary
