6Z4U | pdb_00006z4u

X-ray Crystallographic Structure of Orf9b from SARS-CoV-2

PDB DOI: https://doi.org/10.2210/pdb6Z4U/pdb

Classification: VIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2020-05-25 Released: 2020-06-17
Deposition Author(s): Weeks, S.D., De Graef, S., Munawar, A.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free:
0.257 (Depositor), 0.254 (DCC)
R-Value Work:
0.217 (Depositor)
R-Value Observed:
0.219 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6Z4U

This is version 1.1 of the entry. See complete history.

Literature

X-ray Crystallographic Structure of Orf9b from SARS-CoV-2

Weeks, S.D., De Graef, S., Munawar, A.

To be published.

Macromolecule Content

Total Structure Weight: 23.15 kDa
Atom Count: 1,312
Modeled Residue Count: 166
Deposited Residue Count: 194
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein 9b	A, B	97	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0
UniProt
Find proteins for P0DTD2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD2 Go to UniProtKB: P0DTD2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0DTD2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
15P Query on 15P Download:Ideal Coordinates CCD File SDF format, chain C [auth B] MOL2 format, chain C [auth B] mmCIF format, chain C [auth B]	C [auth B]	POLYETHYLENE GLYCOL (N=34) C₆₉ H₁₄₀ O₃₅ VUYXVWGKCKTUMF-UHFFFAOYSA-N		Interactions Focus chain C [auth B] Interactions & Density Focus chain C [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free: 0.257 (Depositor), 0.254 (DCC)
R-Value Work: 0.217 (Depositor)
R-Value Observed: 0.219 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 36.03	α = 90
b = 64.571	β = 90
c = 73.536	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
DIALS	data reduction
Aimless	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2020-06-17

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2020-06-17
Type: Initial release
Version 1.1: 2024-01-24
Changes: Data collection, Database references, Derived calculations, Refinement description
