6Z18

Crystal structure of RNA-10mer: CCGG(N4,N4-dimethyl-C)GCCGG; R32 form


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.81 Å
  • R-Value Free: 0.288
  • R-Value Work: 0.254
  • R-Value Observed: 0.256

Starting Model: other
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Base pairing, structural and functional insights into N4-methylcytidine (m4C) and N4,N4-dimethylcytidine (m42C) modified RNA.

Mao, S.Sekula, B.Ruszkowski, M.Ranganathan, S.V.Haruehanroengra, P.Wu, Y.Shen, F.Sheng, J.

(2020) Nucleic Acids Res 48: 10087-10100

  • DOI: https://doi.org/10.1093/nar/gkaa737
  • Primary Citation of Related Structures:
    6WY2, 6WY3, 6Z18

  • PubMed Abstract:

    The N4-methylation of cytidine (m4C and m42C) in RNA plays important roles in both bacterial and eukaryotic cells. In this work, we synthesized a series of m4C and m42C modified RNA oligonucleotides, conducted their base pairing and bioactivity studies, and solved three new crystal structures of the RNA duplexes containing these two modifications. Our thermostability and X-ray crystallography studies, together with the molecular dynamic simulation studies, demonstrated that m4C retains a regular C:G base pairing pattern in RNA duplex and has a relatively small effect on its base pairing stability and specificity. By contrast, the m42C modification disrupts the C:G pair and significantly decreases the duplex stability through a conformational shift of native Watson-Crick pair to a wobble-like pattern with the formation of two hydrogen bonds. This double-methylated m42C also results in the loss of base pairing discrimination between C:G and other mismatched pairs like C:A, C:T and C:C. The biochemical investigation of these two modified residues in the reverse transcription model shows that both mono- or di-methylated cytosine bases could specify the C:T pair and induce the G to T mutation using HIV-1 RT. In the presence of other reverse transcriptases with higher fidelity like AMV-RT, the methylation could either retain the normal nucleotide incorporation or completely inhibit the DNA synthesis. These results indicate the methylation at N4-position of cytidine is a molecular mechanism to fine tune base pairing specificity and affect the coding efficiency and fidelity during gene replication.


  • Organizational Affiliation

    Department of Chemistry, University at Albany, State University of New York, 1400 Washington Ave. Albany, NY 12222, USA.


Macromolecules

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains LengthOrganismImage
RNA-10mer: CCGG(N4,N4-dimethyl-C)GCCGG
A, B
10synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.81 Å
  • R-Value Free: 0.288
  • R-Value Work: 0.254
  • R-Value Observed: 0.256
  • Space Group: H 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.562α = 90
b = 42.562β = 90
c = 165.919γ = 120
Software Package:
Software NamePurpose
XDSdata reduction
STARANISOdata scaling
PHASERphasing
PHENIXrefinement

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (NSF, United States)United StatesCHE-1845486
National Science Foundation (NSF, United States)United StatesMCB-1715234
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesIntramural Research Program

Revision History  (Full details and data files)

  • Version 1.0: 2020-09-02
    Type: Initial release
  • Version 1.1: 2021-03-17
    Changes: Database references
  • Version 1.2: 2024-05-01
    Changes: Data collection, Database references, Refinement description
