6YJE | pdb_00006yje

Plasmoodium vivax phosphoglycerate kinase bound to nitrofuran inhibitor from PEG3350 and ammonium acetate at pH 5.5

PDB DOI: https://doi.org/10.2210/pdb6YJE/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Plasmodium vivax
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2020-04-03 Released: 2021-04-14
Deposition Author(s): Blaszczyk, B.K., Hyvonen, M.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.62 Å
R-Value Free:
0.232 (Depositor), 0.238 (DCC)
R-Value Work:
0.196 (Depositor), 0.202 (DCC)
R-Value Observed:
0.198 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6YJE

Ligand Structure Quality Assessment

This is version 2.1 of the entry. See complete history.

Literature

Phosphoglycerate Kinase as a potential target for antimalarial therapy

Bilsland, E., Costa, F., Blaszczyk, B.K., Hyvonen, M., Sunnerhagen, P.

To be published.

Macromolecule Content

Total Structure Weight: 45.52 kDa
Atom Count: 3,567
Modeled Residue Count: 416
Deposited Residue Count: 416
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phosphoglycerate kinase	A	416	Plasmodium vivax	Mutation(s): 0 Gene Names: PVC01_070025900, PVP01_0721000, PVT01_070026100 EC: 2.7.2.3
UniProt
Find proteins for A5K6T9 (Plasmodium vivax (strain Salvador I)) Explore A5K6T9 Go to UniProtKB: A5K6T9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A5K6T9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
OTQ (Subject of Investigation/LOI) Query on OTQ Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	(2~{S})-2-(5-nitrofuran-2-yl)-2,3,5,6,7,8-hexahydro-1~{H}-[1]benzothiolo[2,3-d]pyrimidin-4-one C₁₄ H₁₃ N₃ O₄ S MOKSPNCNIWVHBB-LBPRGKRZSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.62 Å
R-Value Free: 0.232 (Depositor), 0.238 (DCC)
R-Value Work: 0.196 (Depositor), 0.202 (DCC)
R-Value Observed: 0.198 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.962	α = 90
b = 81.246	β = 90
c = 124.331	γ = 90

Software Package:

Software Name	Purpose
BUSTER	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2021-04-14

Deposition Author(s):

Blaszczyk, B.K.

Revision History (Full details and data files)

Version 1.0: 2021-04-14
Type: Initial release
Version 2.0: 2022-05-11
Changes: Database references, Non-polymer description, Structure summary
Version 2.1: 2024-01-24
Changes: Data collection, Refinement description
