6YIR | pdb_00006yir

Crystal structure of Bacillus subtilis MsmX ATPase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.68 Å
  • R-Value Free:
    0.249 (Depositor), 0.254 (DCC)
  • R-Value Work:
    0.197 (Depositor), 0.203 (DCC)
  • R-Value Observed:
    0.200 (Depositor)

Starting Models: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6YIR

This is version 1.2 of the entry. See complete history

Literature

Multitask ATPases (NBDs) of bacterial ABC importers type I and their interspecies exchangeability.

Leisico, F.Godinho, L.M.Goncalves, I.C.Silva, S.P.Carneiro, B.Romao, M.J.Santos-Silva, T.de Sa-Nogueira, I.

(2020) Sci Rep 10: 19564-19564

  • DOI: https://doi.org/10.1038/s41598-020-76444-0
  • Primary Citation Related Structures:
    6YIR

  • PubMed Abstract:

    ATP-binding cassette (ABC) type I importers are widespread in bacteria and play a crucial role in its survival and pathogenesis. They share the same modular architecture comprising two intracellular nucleotide-binding domains (NBDs), two transmembrane domains (TMDs) and a substrate-binding protein. The NBDs bind and hydrolyze ATP, thereby generating conformational changes that are coupled to the TMDs and lead to substrate translocation. A group of multitask NBDs that are able to serve as the cellular motor for multiple sugar importers was recently discovered. To understand why some ABC importers share energy-coupling components, we used the MsmX ATPase from Bacillus subtilis as a model for biological and structural studies. Here we report the first examples of functional hybrid interspecies ABC type I importers in which the NBDs could be exchanged. Furthermore, the first crystal structure of an assigned multitask NBD provides a framework to understand the molecular basis of the broader specificity of interaction with the TMDs.


  • Organizational Affiliation
    • XTAL - Macromolecular Crystallography Laboratory, UCIBIO, Departamento de Química, Faculdade de Ciências E Tecnologia, Universidade NOVA de Lisboa, Quinta da Torre, 2829-516, Caparica, Portugal.

Macromolecule Content

  • Total Structure Weight: 42.69 kDa
  • Atom Count: 3,234
  • Modeled Residue Count: 366
  • Deposited Residue Count: 373
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Oligosaccharides import ATP-binding protein MsmX373Bacillus subtilis subsp. subtilis str. 168Mutation(s): 1
Gene Names: msmXyxkGBSU38810
EC: 7.5.2
UniProt
Find proteins for P94360 (Bacillus subtilis (strain 168))
Explore P94360
Go to UniProtKB:  P94360
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP94360
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.68 Å
  • R-Value Free:  0.249 (Depositor), 0.254 (DCC)
  • R-Value Work:  0.197 (Depositor), 0.203 (DCC)
  • R-Value Observed: 0.200 (Depositor)
Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 86.758α = 90
b = 94.247β = 90
c = 132.263γ = 90
Software Package:
Software NamePurpose
MxCuBEdata collection
XDSdata reduction
STARANISOdata scaling
Aimlessdata scaling
ARP/wARPmodel building
Cootmodel building
PHASERphasing
REFMACrefinement

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Fundacao para a Ciencia e a TecnologiaPortugalPTDC/BIA-MIC/30696/2017

Revision History  (Full details and data files)

  • Version 1.0: 2020-11-18
    Type: Initial release
  • Version 1.1: 2020-11-25
    Changes: Database references
  • Version 1.2: 2024-01-24
    Changes: Data collection, Database references, Derived calculations, Refinement description
