6XNM | pdb_00006xnm

GCN4-p1 Peptide Trimer with tyrosine residue at position 16

• PDB DOI: https://doi.org/10.2210/pdb6XNM/pdb

• Classification: TRANSCRIPTION
• Organism(s): Saccharomyces cerevisiae
• Mutation(s): Yes


• Deposited: 2020-07-03 Released: 2021-07-07
• Deposition Author(s): Rowe Hartje, R.K., Czarny, R.S., Ho, A.
• Funding Organization(s): National Science Foundation (NSF, United States)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.25 Å
• R-Value Free:
  0.358 (Depositor), 0.357 (DCC)
• R-Value Work:
  0.225 (Depositor), 0.225 (DCC)
• R-Value Observed:
  0.238 (Depositor)

Starting Model: experimental

Literature

Engineering Specific Protein-Protein Interactions Through Halogen and Hydrogen Bonds

Rowe Hartje, R.K., Ferrero, M., Cavallo, G., Metrangolo, P., Ho, A., Czarny, R., Ho, P.S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 11.11 kDa
• Atom Count: 819
• Modeled Residue Count: 90
• Deposited Residue Count: 90
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GCN4-p1 peptide with A16	A, C	30	Saccharomyces cerevisiae	Mutation(s): 1
UniProt
Find proteins for P03069 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c)) Explore P03069  Go to UniProtKB:  P03069

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
GCN4-p1 peptide with Y16	B	30	Saccharomyces cerevisiae	Mutation(s): 1
UniProt
Find proteins for P03069 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c)) Explore P03069  Go to UniProtKB:  P03069

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NA	D [auth A], E [auth A], F [auth B], G [auth B], H [auth C], I [auth C], J [auth C]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.25 Å
• R-Value Free:  0.358 (Depositor), 0.357 (DCC)
• R-Value Work:  0.225 (Depositor), 0.225 (DCC)
• R-Value Observed: 0.238 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.553	α = 90
b = 34.482	β = 100.65
c = 46.936	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-2000	data reduction
HKL-2000	data scaling
PHENIX	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2021-07-07
Deposition Author(s): Rowe Hartje, R.K., Czarny, R.S., Ho, A.

---

Funding Organization	Location	Grant Number
National Science Foundation (NSF, United States)	United States	1608146
National Science Foundation (NSF, United States)	United States	1905328

Revision History

• Version 1.0: 2021-07-07
  Type: Initial release

• Version 1.1: 2023-10-18
  Changes: Data collection, Database references, Refinement description
