6XF4

Crystal structure of STING REF variant in complex with E7766


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.77 Å
  • R-Value Free: 0.271
  • R-Value Work: 0.221
  • R-Value Observed: 0.224

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

E7766, a Macrocycle-Bridged Stimulator of Interferon Genes (STING) Agonist with Potent Pan-Genotypic Activity.

Kim, D.S.Endo, A.Fang, F.G.Huang, K.C.Bao, X.Choi, H.W.Majumder, U.Shen, Y.Y.Mathieu, S.Zhu, X.Sanders, K.Noland, T.Hao, M.H.Chen, Y.Wang, J.Y.Yasui, S.TenDyke, K.Wu, J.Ingersoll, C.Loiacono, K.A.Hutz, J.E.Sarwar, N.

(2021) ChemMedChem 16: 1740-1743

  • DOI: https://doi.org/10.1002/cmdc.202100068
  • Primary Citation of Related Structures:
    6XF3, 6XF4

  • PubMed Abstract:

    A strategy for creating potent and pan-genotypic stimulator of interferon genes (STING) agonists is described. Locking a bioactive U-shaped conformation of cyclic dinucleotides by introducing a transannular macrocyclic bridge between the nucleic acid bases leads to a topologically novel macrocycle-bridged STING agonist (MBSA). In addition to substantially enhanced potency, the newly designed MBSAs, exemplified by clinical candidate E7766, exhibit broad pan-genotypic activity in all major human STING variants. E7766 is shown to have potent antitumor activity with long lasting immune memory response in a mouse liver metastatic tumor model. Two complementary stereoselective synthetic routes to E7766 are also described.


  • Organizational Affiliation

    Eisai Inc., 35 Cambridgepark Drive, Cambridge, MA 02140, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Stimulator of interferon genes protein
A, B
189Homo sapiensMutation(s): 0
Gene Names: STING1ERISMITATMEM173
UniProt & NIH Common Fund Data Resources
Find proteins for Q86WV6 (Homo sapiens)
Explore Q86WV6
Go to UniProtKB:  Q86WV6
PHAROS:  Q86WV6
GTEx:  ENSG00000184584
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ86WV6
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
V5V (Subject of Investigation/LOI)
Query on V5V

Download Ideal Coordinates CCD File
C [auth A](1R,3R,15E,28R,29R,30R,31R,34R,36R,39S,41R)-29,41-difluoro-34,39-disulfanyl-2,33,35,38,40,42-hexaoxa-4,6,9,11,13,18,20,22,25,27-decaaza-34,39-diphosphaoctacyclo[28.6.4.1~3,36~.1~28,31~.0~4,8~.0~7,12~.0~19,24~.0~23,27~]dotetraconta-5,7,9,11,15,19,21,23,25-nonaene 34,39-dioxide (non-preferred name)
C24 H26 F2 N10 O8 P2 S2
YQSAUMRQALUWNS-VUCARUFASA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth B]
G [auth B]
H [auth B]
D [auth A],
E [auth A],
F [auth B],
G [auth B],
H [auth B],
I [auth B]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.77 Å
  • R-Value Free: 0.271
  • R-Value Work: 0.221
  • R-Value Observed: 0.224
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 33.733α = 90
b = 77.831β = 90
c = 131.689γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-3000data scaling
PHASERphasing
Cootmodel building
HKL-3000data reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-02-17
    Type: Initial release
  • Version 1.1: 2021-06-16
    Changes: Database references
  • Version 1.2: 2024-03-06
    Changes: Data collection, Database references, Refinement description
  • Version 1.3: 2024-04-03
    Changes: Refinement description
